China RF 40ll Vertical Pressure Steam Sterilizer for Medical Sterile

Product Description

Product Description APPLICATION: Autoclaves are for sterilizing widely used in medical product that need to be sterilized
PRINCIPLE:As a type of high pressure sterilizer, it takes steam as its sterilization medium which is fast, safe and economic.
Product Features:
1.Basic structure:
A: The shell case is made of high temperature thermoplastic material with outstanding impact resistance and stainless steel.
B: The pot body of sterilizer is made of food grade stainless steel(304)
C: The lid opening and closing device adopts the lever type multi-link synchronous telescopic structure,which makes the lid and the pot body open and close flexible and light,safe and reliable.
2.Control and operation
The console uses the LCD window graphic dynamic display,the whole sterilization process is controlled by microcomputer display and automatic cycle control,and the machine stops automatically after the end of sterilization (alarm)
3.Function description
A:It has a one-button sterilization function selection,which can make a quick and clear choice based on different items.
B:With air-cooled chilling device to ensure that the pot body is quickly cooled at the end of sterilization,thus reducing the time to open the lid.
C:Automatic fault detection and judgment system is in place.
D:The full-automatic control model has the function of discharging the low temperature air and steam internal exhaust and exhausting steam when sterilization procedure ends.
4.Safety device
A:Adopt the safety interlock structure of electrical and mechanical interaction to ensure that the interlock device locks the lid handle when there is pressure in the pot to avoid opening the lid when there is pressure in the pot .
B:Double protection system with the mechanical safety relief valve and electronically controlled over voltage protective device.
C:It has heater anti-drying protection function and leakage protection system.

Detailed Photos

Product Parameters

Parameter/Model	RF-40KCY RF-40KCY-1	RF-60KCY RF-60KCY-1	RF-80KCY RF-80KCY-1
configuration	Semi-auto	Semi-auto	Semi-auto
Material (mm)	Stainless steel	Stainless steel	Stainless steel
Pot wall thickness(mm)	2.0	2.0	2.0
G.W	94kg/97kg	99kg/102kg	108kg/112kg
Voltage/power	220v/3.5kw	220v/3.5kw	220v/3.5kw
Packing size(mm)	790×670×1160	790×670×1160	790×670×1320
Product size(mm)	570×690×1020	570×690×1020	570×690×1170
Use volume(D*H mm)	350×400	350×550	350×700
Basket size(D*H mm)	335×190	335×190(×2)	335×190 335×360
Time setting range	1-999min	1-999min	1-999min
Rated working pressure	0.217MPa	0.217MPa	0.217MPa
Temperature setting range	50-134ºC	50-134ºC	50-134ºC

Certifications
Packaging & Shipping
Our Advantages A.Our technical team is strong (20 person)
B.Our service of after sales team is strong
C.Our manufacture experience is around 40years
Company Profile
FAQ:
1.Who are we?
Market:We are based in Hebei, China, start from 1986,sell to Africa,Western Europe,South America,North America,Southeast
Asia,Mid East,Central America,South Asia,Eastern Europe,Northern Europe,Oceania,Southern Europe,Eastern Asia
There are total about 101-200 people in our office.
What we do?
We are specialized in medical equipment and sterilization equipment.at present ,we had expended many types sterilizer:Ethylene oxide sterilizer ,steam sterilizer ,high pressure sterilizer and other ancillary facility.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Ethylene oxide sterilizer ;
Steam sterilizer (high pressure steam sterilizer ,autoclave,various capacity ,different type ,widely application,pharmaceutical engineering,biology,medical,hospital,Lab ,food and so on )
4. why should you buy from us not from other suppliers?
Ouer company founded in 1986 and been through high and stable development for around 40 years, who is now with revenues of ninety
million,50 acres land industry parks and 20000 square meters production base.our workshop equipped with advanced production equipment
5.Visit
Dear customer, you are very welcome to visit our factory . I will give you a detailed introduction on site.
We are an hour's drive from the nearest Tianjin Airport.
6.MOQ
1 UNITS
7. Payment&Delivery
Accepted Delivery Terms: FOB,CIF,EXW;DDP,DDU
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A; We prefer T/T.
8.service
* Online guidance, 1-year warranty after sale.
Product guidance installation, product quality problems contact me, we have a strong after-sales team.
