4 Cavity Pet Blow Moulding Machine (BM-A4)
| US$48,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BM-A4
Raw Material
PET
Making Method of Parison
Stretch Blow
Automation
Automatic
Computerized
Computerized
Certification
CE
After-sales Service
2 Year
Transport Package
Wooden Case
Specification
SGS
Trademark
Mars
Origin
Zhangjiagang
HS Code
8477300000
Production Capacity
180 PCS/Month
Product Description
4 Cavity Pet Blow Moulding Machine (BM-A4):BM-A4 Full automatic bloing bottle machine is suitable for producing PET/PE and PP plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.
Reasonable design, full automatic control, save power and labor.
Adopt high quality components.
Feeding system carries the performs by robot automatically.
Infrared oven heater adopts the quartz lamp to heat the PET tube.
Fully automatic process with low investment, high efficiency, quick and safe operation, easy for trouble -shooting, maintenance and other benefits.
We have perfect service after sales
| Main part: | ||
| Pneumatic part | Valve | AIR TAC/SMC |
| Cylinder | ||
| Electric part | PLC | LG |
| Operating system | LG | |
| Relay | OMRON | |
| Infrared thermometer | America Raytek | |
| Note | All of the electrical components adopts CE/UL / CCC approved international advanced high-tech product. | |
| Main parameter: | ||
| Model | BM-A4 | |
| Productivity | Depend on bottle design | 3500-3800 Pcs/Hour |
| Product type | Body diameter | ≤ 100mm |
| Height | ≤ 310mm | |
| Neck diameter | 18-38mm | |
| Mold | Cavity | 4 cavity |
| Mold thick | 240mm | |
| Mold | 260*240*370mm | |
| Main machine power | Electrical source power | 380V/220V 50/60Hz |
| Rated Power | 49KW | |
| Really use power | 10-15KW | |
| Air source | LP air compressor | 1.6m3 /min 10Kg |
| HP air compressor | 2.0m3 /min 30Kg | |
| Air dryer | 2.0m3 /min 30Kg | |
| Cooling water | Cooling water | 15L/Min |
| Size | L*W*H | 1910*1858*1935mm |
| Weight | 3600Kg | |
| Auxiliary equipment( pre-form unscrambler) | L*W*H | 2000*950*2480mm |
| Weight | 250Kg | |
| Resin available | PET | |
