Oil Country Lathe Q1327, Big Bore Lathe with Double Chuck

Product Description

Product description:
Technical parameter :
Technical parameter :

Specifications		UNIT	Q1327
Capacity	Swing over bed	mm	1000
	Swing over cross slide	mm	610
	Distance between centers	mm	1500/3000
	Pipe threading range	mm	Ø130-270
	Width of bed way	mm	755
	Max.load capacity	T	5
Spindle	Spindle bore	mm	Ø280
	Spindle speed steps	-	12 steps
	Spindle speed range	rpm	16-380
	Chuck size	mm	800
	Chuck type	-	4-jaw manual
Turret	Turret type	-	Manual 4 position
	Tool shank size	mm	40x40
	Turret travel	mm	300
Carriage	X axis feed grade/range	mm/r	64/0.05-12.15
	Z axis feed grade/range	mm/r	64/0.1-24.3
	X axis rapid traverse speed	mm/min	1870
	Z axis rapid traverse speed	mm/min	3740
	X axis travel	mm	520
	Z axis travel	mm	1310/2810
Tailstock	Tailstock quill diameter	mm	140
	Tailstock quill taper	-	MT6
	Tailstock quill travel	mm	300
Motors	Main spindle motor	kW	22
	Rapid traverse motor	kW	1.5
	Coolant pump motor	kW	0.125
Thread	Metric thread grade/range	mm	30/1-30
	Inch thread grade/range	T.P.I.	27/1-28
Dimensions	Width x Height	mm	2100X1600
	Length	mm	4190/5690
Weight	N.W./G.W.	T	10.0/11.5

Standard accessories:
3-jaw chucks,
Tapper turning attachment,
Work lamp,
Coolant pump,
Rear support bracket,
Optional accessories:
Digital readout,
Bigger size chuck,
Face plate,
Thread chasing dial,
Steady rest,
Follow rest
Protective cover
Grinding attachment etc. Company information:
