FST100-2008 Weather Station with Rain Gauge
| US$142.00-165.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FST100-2008
Type
Angle Block Gauge
Material
Stainless Steel
Measurement Object
Depth
Resolution
0.02mm
Precision
0.02mm
Measure Method
Automatic
Accuracy
A
Precision Measuring Device
Precision Measuring Device
Certification
CE
Customized
Customized
Barrel Inlet Size
Diameter 200mm
Power Voltage
5-24V DC 12-24V DC
Output Signal 1
Voltage Signal
Output Signal 2
Current Signal
Output Signal 3
Pulse Signal
Output Signal 4
RS485
Rainfall collector
200mm
Environment temperature
-10-50ºC
Size
216*460mm
Electrical connections
Direct Lead
Transport Package
Standard Export Packing
Specification
standard export packing
Trademark
Firstrate
Origin
Changsha China
HS Code
9015800090
Production Capacity
50000pieces/Month
Product Description
FST100-2008 Weather Station with Rain GaugeProduct Description
| Product number | FST100-2008 |
| Measuring range | Rain intensity range: 0.01mm~4mm/min (allowable maximum rain intensity 8mm/min) |
| Output signal | RS485 output (Modbus protocol) pulse |
| Supply voltage | Analog signal: 12~24VDC Digital signal: 5~24VDC |
| Maximum power consumption | Static 0.16W Dynamic 1.8W |
| Precision | Accuracy ≤±3% |
| Resolution | 0.2mm |
| Operating temperature | -10~50ºC Relative humidity<95% (40ºC) |
| Device address | 1~255 can be set, the default is 1 |
| Device baud rate | Standard MODBUS-RTU protocol, baud rate 9600 |
| Byte format | 8 data bits, 1 stop bit, no parity |
| Electrical connections | Direct lead |
Company Information
FAQ
Q: Are you manufacturer?
A: Yes, We are professional sensor manufacturer over 50 years! Our technical team has more than 20 engineers.
Q: Can you accept OEM service ?
A: Yes, we can put your company information and logo on our sensors.
Q: Can I be your distributor?
A: Yes, we are looking for distributors in oversea market.
Q: What is your lead time?
A: Normally 7-10days. For quantity above100pcs, need extra 3-5 working days.
