Universal Lathe Machine Metal Turning C6241 C6246 C6256 C6266
| US$4,000.00-8,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
C6241 C6246 C6256 C6266
Type
Horizontal Lathe
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Max.Swing Over Bed
410mm
Swing Over Cross Slide
220mm
Width of Bed
300mm
Spindle Bore
58mm
Spindle Taper
Mt6
Transport Package
Plywood Case
Specification
3200kgs
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
84581900
Production Capacity
10 PCS/Month
Product Description
METAL LATHE MACHINE FEATURES:
The guide way and all gears in the head stock are hardened and precision ground.
The spindle system is high rigidity and accuracy.
The machines have powerful head stock gear train, high rotating accuracy and smooth running with low noise.
An overload safety device is provided on the apron.
Pedal or electromagnetic braking device.
Tolerance test certificate, test flow chart included
SPECIFICATIONS:
| SPECIFICATION | MODEL | |||||||||||
| C6241×1000 | C6241V×1500 | C6246×2000 | C6246V×1000 | C6246V×1500 | C6246V×2000 | |||||||
| Capacity | ||||||||||||
| Swing over bed | 410 | 460 | ||||||||||
| Swing over cross slide | 220 | 270 | ||||||||||
| Swing in gap diameter | 640 | 690 | ||||||||||
| Distance between centers | 1000 | 1500 | 2000 | 1000 | 1500 | 2000 | ||||||
| Valid length of gap | 165mm | |||||||||||
| Width of bed | 300mm | |||||||||||
| Headstock | ||||||||||||
| Spindle nose | D1-6 | |||||||||||
| Spindle bore | 58mm | |||||||||||
| Taper of spindle bore | No.6 Morse | |||||||||||
| Range of spindle speed | 12 changes, 25~2000r/min | |||||||||||
| Feeds and threads | ||||||||||||
| Compound rest travel | 128mm | |||||||||||
| Cross slide travel | 285mm | |||||||||||
| Max.section of tool | 25×25mm | |||||||||||
| Lead screw thread | 6mm or 4T.P.I. | |||||||||||
| Longitudinal feeds range | 42 kinds, 0.031~1.7mm/rev(0.0011"~0.0633"/rev) | |||||||||||
| Cross feeds range | 42 kinds, 0.014~0.784mm/rev(0.00033"~0.01837"/rev) | |||||||||||
| Threads metric pitches | 41 kinds, 0.1~14mm | |||||||||||
| Threads imperial pitches | 60 kinds, 2~112T.P.I. | |||||||||||
| Threads diametral pitches | 50 kinds, 4~112DP | |||||||||||
| Threads module pitches | 34 kinds, 0.1~7MP | |||||||||||
| Tailstock | ||||||||||||
| Quill diameter | 60mm | |||||||||||
| Quill travel | 130mm | |||||||||||
| Quill taper | No.4 Morse | |||||||||||
| Motor | ||||||||||||
| Main motor power | 5.5kW(7.5HP) 3PH | |||||||||||
| Coolant pump power | 0.1kW(1/8HP) 3PH | |||||||||||
| Dimension and weight | ||||||||||||
| Overall dimension(L×W×H) | 220×108×134 | 275×108×13 | 325×108×134 | 220×108×137 | 275×108×137 | 325×108×137 | ||||||
| Packing size(L×W×H) | 225×112×162 | 280×112×156 | 330×113×156 | 225×112×162 | 280×112×156 | 330×113×156 | ||||||
| Net weight | 1580kg | 1745kg | 1900kg | 1645kg | 1810kg | 1965kg | ||||||
| Gross weight | 1845kg | 2050kg | 2230kg | 1910kg | 2115kg | 2295kg | ||||||
