Diameter 10 11 12 13mm Glue Wax Guiding Aramid Kevlar Paper Carrier Rope with Core for Paper Machine Dryer Cylinder
| US$1.80-7.50 | 1 Piece (MOQ) |
Basic Info.
Model NO.
LZPCR
Certification
RoHS, ISO 9001:2000, CE
Surface Treatment
Wax or No Wax
Manufacturing Process
Woven
Material
DuPont Fiber
Diameter
8,10,11,12,14
Function
Leading and Carry Paper Sheet
Delivery Time
7 Days
OEM Service
Support
Transport Package
Standard Seaworthy Package
Specification
Customized
Trademark
LEIZHAN
Origin
China
HS Code
84399900
Production Capacity
5000PCS /Year
Packaging & Delivery
Package Size
30.00cm * 30.00cm * 40.00cm
Package Gross Weight
20.000kg
Product Description
Product DescriptionPaper Machine Paper Carrier Rope
Paper carrier rope is a high-temperature, quality-impregnated filament nylon rope. Applied to each thread by the China lift sling group developed method, the improved impregnation gives greater protection to the fibers of the rope and an excellent surface for gripping the paper tail. The unique hollow braided construction resists flattening under normal operating tension, further enhancing its threading efficiency and ease of splicing. If extra resistance to elongation is required, an option is available in filament polyester, specifically designed for wet conditions.
Detailed Photos
Product Parameters
The paper carrier rope is a rope used for threading, which is woven from nylon fibers. It is a necessary paper threading tool for paper machines in paper mills. It is the connecting link of all rollers of various sizes in various paper machine parts such as sizing, coating, post-drying, and reel. It is responsible for pulling the narrow paper web from one roller to another. Its function is very important. Parameters:
| Nominal Diameter | Linear density | Minimum breaking strength | Elongation | |
| Nominal Value (ktex) | Allowable Deviation(%) | |||
| 8 | 52 | ±5 | 10800 | 30 |
| 10 | 72 | 14700 | ||
| 12 | 78 | 16700 | ||
| 14 | 84 | 18080 | ||
| 16 | 110 | 22000 | ||
| Remark:1 ktex=1 g/m | ||||
