Accept Custom Waste Plastic Recycling Machine

Accept Custom Waste Plastic Recycling Machine

US$66,300.00-68,300.00 1 Set (MOQ)

Basic Info.

Model NO.
ZX-530 Waste Plastic Recycling Machine
Type
Injection Blow Molding
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Motor Type
Servo Motor
Injection Weight
2219g
Space Between Tie Bars
830 X 830 mm
Products
Pet Preform, Household, Pipe Fitting, Cars Lamp
Transport Package
1PC/Plastic Film
Specification
9.1 x 2.1 x 2.5 M
Trademark
Zhenyue / OEM / ODM
Origin
China
HS Code
8474809090
Production Capacity
100PCS/Month

Product Description

Zhengyue Accept Custom Waste Plastic Recycling Machine
Features:
User friendly: Easy nozzle alignment after injection carriage improved. Easy care and maintenance.
Precision: high optimistic mechanical structure with high-tech controller, greatly increase machine service life and precise.
Speedy: High injection speed reducing cycle time.
Durable: Thicker platens to add strength, free from deforming molds.
Stable: dual cylinder injection, perform stability and reliability.
ZX-530 Injection Unit Date A B C
Screw diameter mm 80 85 90
Screw L/D ratio / 22.3 21 19.8
Theoretical shot volume cm3 2136 2412 2704
Shot weight(PS) g 1965 2219 2487
Injection rate g/s 473 534 599
Max.screw speed rpm 150
Clamping Unit
Clamping force KN 5300
Toggle stroke mm 800
Space bettween tie bars mm 830x830
Min.mold thickness mm 330
Max.mold thickness mm 800
Hydraulic ejection stroke mm 210
Hydraulic ejection force KN 126
Others
Hydraulic system pressure Mpa 17.5
Pump motor kw 32+32
Heating capacity kw 32
Oil tank capacity L 1000
Machine dimensions m 9.1x2.1x2.5
Machine weight Ton 25

Dimension:
Zhengyue Group is a specialized company engaging in the Research, Development ,Production and Sales of Mechanical and electrical integrated products.
There are mainly five product series Including: CNC Miller, Machining Center, Plastic Injection Molding Machine, CNC wire cutting Machine, CNC Electrical Impulse.
In recent years Zhenyue has got honours in succession, e.g."One of Top Hundred Key Enterprises in Ningbo", "AAA Credit Company in Ningbo", ETC.
Zhengyue products won HI-tech Prize and New Product Prize of the Municipal ,Provincial and State Level. The total construction scale of Zhengyue reaches to 66,000 square meters. With a first-class managing center ,it now has over 500 workers and staffs, among which 30% are R&D personnel. This R&D team allows Zhengyue to develop new products with the worlds most advanced technology.
After-Sale Service :
1. Technical files service provided.
2. On-site training service provided.
3. Free training course at our plant.
4. Lifetime maintenance free of charge.
5. Technical support online service provided.
6. Spare parts replacement and repair service provided.
7. We will provide the consumable parts at an agency price when you need replacement.
FAQ :
How long is the delivery time?
For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
How is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading
