Home Use Small Flat Die Wood Pellet Mill Grass Corn Pellet Mill

Product Description

P Product Description
Pls contact Tina for more details
Wood pellet machine is new generation of energy-saving products, researched and developed by our researcher newly. It is mainly used to compress crushed corn straw, sawdust, plant waste, bamboo powder, grass, sunflower stalk, straw, rice husk, forestry waste, wood chips, chemical waste and etc.Small model suitable for the animal feed,big model suitable for biomass.The raw materials can be grains like corn, wheat and the crushed waste from agriculture and sawdust. The input raw material moisture should be about 13%-18%, most popular finished pellets diameter is 2.5mm, 3mm, 4mm, 6mm, 8mm.

Machine structure

Product Parameters

Model	Power	Capacity	Dimension	Weight
125	4kw	80-100kg/h	850*350*520mm	75kg
150	4kw	100-150kg/h	850*350*570mm	81kg
210	7.5kw	300-450kg/h	990*430*710mm	165kg
260	11/15kw	600-800kg/h	1300*450*1100mm	290kg
300	22kw	1000-1200kg/h	1360*570*1150mm	400kg
400	30kw	1500-1800kg/h	1550*620*1250mm	680kg

Application
Molds
Machine display
Advantage:1.The flat die feed pellet making machine are easier to clean than the ring die pellet mill.2.Able to change die and roller faster and easily.3.Small and lightweight, making small-scale production possible.4.Visibility. It is possible to view into the chamber when pelletizing, you can solve any problem timely.5.The main features of the feed pellet mill: high energy efficiency, reasonable structure, work reliable, wide adaptability, elegant, easy to clean, easy to operate.

Factory
