Mo-La/Tzm Molybdenum Alloy High Temperature Tensil Strength

Product Description

Materials: Pure Moly 99.95% min,
TZM alloy , Mo-La alloy
Properties:
1. Molybdenum is the most commonly used of the refractory metals.
With a high melting temperature of 2620°C, Molybdenum also has excellent high temperature strength. Besides, molybdenum has very good thermal and electrical conductivity, and resistant to corrosion. With all the characteristics combined, molybdenum is widely used in electric furnace, semiconductors, radiation products, sputtering targets, etc.
2.TZM
Titanium-Zirconium-Molybdenum alloy, also known as TZM, comprimised of 0.50% Titanium, 0.08%Zirconium, and 0.01-0.04% Carbon is a great high strength solution for high temperature applications.TZM is stronger than pure molybdenum and possesses a higher recrystallization temperature and better creep resistance. Commonly used in applications involving demanding mechanical loads, it's recommended use temperature is between1292°F (700°C) & 2552°F (1400°C).
3.Mola
Molybdenum-Lanthom Oxide, also known as Mola, is an alloyed metal manufactured to provide specific advantages over pure Moly. This alloyed metal is made by adding Lanthanum Oxide during the manufacturing process, giving the molybdenum a so-called stacked fiber microstructure which is stable at temperatures up to 2632F(2000C). This microstructure allows the alloy to be creep- resistant under shear strength, higher tensile strength, and greater resistance to deformation at high temperatures. Mola is an ideal material for applications requiring dimensional stability and strength at temperatures above the capabilities of pure Moly or TZM.
Molybdenum products application: High temperature heating elements, radiation shields, extrusions, forging dies, etc; Rotating X-ray anodes used in clinical diagnostics; Glass melting furnace electrodes and components that are resistant to molten glass; Heat sinks with thermal expansivity matching silicon for semiconductor chip mounts; Sputtered layers, for gates and interconnects on integrated circuit chips.
Company Profile Company Introduction:
Sincemat Co., Ltd is an outstanding manufacturer of Titanium, Nickel, Tungsten, Molybdenum, Tantalum, Niobium series products in China, established in 2003.The types of our materials include tube/pipe, strip/sheet/plate, bar/rod/wire, fittings, forgings, machining parts, target, crucible, boat, fasteners etc. We focus on providing highest possible quality, most competitive price, prompt delivery, excellent service for our customers. Our mission is to make our customer most satisfied. We sincerely hope that our work will bring more value for our customers.
Our company has a complete quality assurance system, has ISO9001:2015 quality system certified, and established a quality assurance system in strict accordance with GB(National Standard), ASTM/ASME/AWS(American Standard), DIN/EN(Europe Standard), ISO(International Organization Standard) and other product standards. We can meet the requirements of various materials and products from our customers.
During the past several years, we have invested to improve our production line with new technology and equipment, production efficiency has been greatly improved and more high-tech products have been developed. We will keep investing new technology and optimizing our production line and sales chain, we are determined to serve our customers' every need with best products best service. At the same time, the principle we always hold is to put the cost to lowest in various parts when the quality is guaranteed, which enable us to provide the most competitive price for customer. Meanwhile, we always try our best to deliver our products as soon as possible.
