DJ901 Self-Loading Mixer Truck with 2X210L Water Tank, Electronic Weighing System, Steel Wire Tire, 290 Degree Rotating Mixer Tank Unloading

DJ901 Self-Loading Mixer Truck with 2X210L Water Tank, Electronic Weighing System, Steel Wire Tire, 290 Degree Rotating Mixer Tank Unloading

US$26,000.00
1-9 Pieces
US$25,500.00
10-49 Pieces
US$25,000.00
50+ Pieces

Basic Info.

Model NO.
DJ901
Type
Concrete Mixing Truck
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
16m3
Feeding Height
3380mm
Vibrating Amplitude
1.3mm
Certification
ISO9001: 2000, CE
Condition
New
Color
White
Specification
7500*2700*3380mm
Trademark
DAOJ
Origin
Shandong Qingzhou
HS Code
8429510000
Production Capacity
1000pieces/Year

Product Description

Basic Parameters
Drum capacity 5.5m³
Concrete output 4m³
Loading ratio 76%
Rotary drum Discharge mouth height 1.8 meters.Level turn 290 ° (options)
Production capacity 4 batches in an hour.16 cubic meters per hour
Engine Yuchai4108 turbo charge, diesel, water cooling
Transmission way Full hydraulic drive.4 wheel drive and 2 turns.All the power comes from hydraulic oil, including walking 4X4
Climbing ability 30%
Speed Low speed 0-25 km/h, high speed 0-45 km/h.
CAB Ultra wide deluxe cab . ROPS type.
Joystick A four-way hydraulic pilot with an electric control button controls the bucket.
Bucket 650L, hydraulic gate.
Chute Equipped with two removable shaft pins to increase the discharge length.
Water supply system Self-priming hydraulic drive pump/electronic water flow monitor/high pressure washer (optional)
Brake inner wheel brake and the emergency brake operate on 4 wheels, enabling the small servo pump on the independent double-return road.Negative pressure type stop brake, the front bridge is equipped with inner hub
Turn Hydraulic steering, rear wheel steering.
Tyre 385/65/22.5
Tires : 405/70-20
Oil tank/water tank 2 x210L water tank. Diesel tank: 125 L.Hydraulic tank: 130 L
Weight 7600KG
L*W*H 7500*2700*3380mm
Wheelbase 2350mm
Metering Electronic weighing system (optional).

Our Concrete Mixer Truck is compact and convenient in design, easy to operate, with a batch output of 4 cubic meters,16 cubic meters per hour. It is a perfect combination of a mixing tank truck, a loader and a transport truck. It also has a 290-degree rotating mixing tank unloading function and a fully hydraulic drive, which is more efficient, more precise and more stable.
About Us
Our Advantages
1.Why choose us?
Choose our construction machinery because we provide efficient, reliable and safe construction solutions. Our products use advanced technology to ensure efficient construction, while focusing on energy conservation and environmental protection, in line with the concept of sustainable development. We have a strong brand strength and a complete after-sales service system, and can provide customers with all-round support. Whether it is a large-scale engineering project or a daily construction task, our construction machinery can meet your needs and help you successfully complete the construction task.
FAQ Q1: How long is the Warranty for DAOJ product? A1: DAOJ provides 12 months or 1000 hours for the whole machine from on board time. Q2: How about the delivery time?
A2: Usually DAOJ producing time is 15- 40 days after we receive the advanced payment. For some standard products, we may have stock and could delivery immediately.
Q3: What kind terms of payment can be accepted?
A3: :Normally we can work on T/T term or L/C term.
Q4: Can DAOJ provide customized products? OEM products or ODM products?
A4: Yes, DAOJcan provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products, welcome your special request.
Q5: Could we request our own color for the products?
A5: Yes, of course
