Rotating Paddle Fork Vibrating Magnetic Float Reed Micro Level Switch for Fuel Oil Water Tank Vessel Flow Control with Sensor

Product Description

Product DescriptionRotating Paddle,Fork Vibrating,Magnetic Float Reed Micro Switch,Level Switch for Fuel Oil or Water Tank Vessel Flow Control with sensor
UQK Float Level Controller
UQK magnetic float liquid level swith consist of reed and magnetic float ball, which is based on the floating principle that utilizes magnetic float ball to make the relevant reed close or open according to the height changng of the liquid level, thus controlling and measuring the liquid level.
Side Mounted Float Level Alarm Switch Liquid fuel diesel Tank Level Sensor Explosion proof
The UQK series is a side mount magnetic float level switch product line consisting of rugged, industrial grade float level switches using the principles of buoyancy and magnetism to provide high, low and intermediate level detection of fluids with specific gravity ranging from as low as 0.25, thereby ensuring a very wide range of application and use. A change in fluid level can correspondingly cause the float to travel up or down. The UQK series side mounted magnetic float level switch product line incorporates SPDT reed switch or SPDT micro switch output and are available in stainless steel or polypropylene wetted materials. Marine certification and explosion proof versions are available.China Cheap Side Mounted Float Level Switch Liquid Tank Level Sensor Level Switch Liquid For Petrochemical 1. Robust Construction: The UQK Marine Switch is constructed using high-quality materials that can endure the challenges posed by the marine environment. It is typically made of corrosion-resistant metals and features a durable housing to protect the internal components.
2. Waterproof Design: One of the critical features of the UQK Marine Switch is its waterproof design. It is specifically designed to prevent water ingress, ensuring reliable operation even in wet conditions. This feature helps to prevent electrical failures caused by moisture or water splashes.
3. Saltwater Resistance: Saltwater can be highly corrosive to electrical components. The UQK Marine Switch is built to resist the corrosive effects of saltwater, making it suitable for use in saltwater environments such as oceans and seas.
4. Vibration Resistance: Marine vessels often experience significant vibrations caused by the engine, waves, and rough seas. The UQK Marine Switch is designed to withstand these vibrations, ensuring that it remains securely in place and maintains its functionality.
5. Versatile Switching Functions: The UQK Marine Switch can be used for various switching functions on board a marine vessel. It can be employed to control lighting systems, electrical equipment, pumps, fans, and other devices, providing a reliable means of managing electrical circuits.
Technical Parameter: Customizable

Model	Model type	Working pressure	Working temperature	Float diameter	Material
					Float	Flange	connection
UQK-10	Side-mounting basic type	1MPa	-30~100ºC	Φ41	SUS304	SUS304	Thread
UQK-10T	Side-mounting extension type	1MPa	-30~250ºC	Φ41	SUS304	SUS304	Flange/thread
UQK-20	Side-mounting different type	1MPa	-30~100ºC	Φ41	SUS304	SUS304	Flange
UQK-20T	Side-mounting large type	1MPa	-30~200ºC	Φ41	SUS304	SUS304	Flange
UQK-21	Side mounting	1MPa	-30~200ºC	Φ75	SUS304	SUS304	Flange
UQK-30	Z TYPE Side mounting	1MPa	-30~100ºC	Φ41	SUS304	SUS304	Flange
UQK-41	High temp Side mounting	1MPa	-30~350ºC	Φ41	SUS304	SUS304	Flange
UQK-50	Top mounteing type	1MPa	-30~100ºC	Φ41	SUS304	SUS304	Flange

Products:other customizable products:
our company :
Rotating Paddle rotary Fork Vibrating Magnetic Float Reed Micro Level Switch for Fuel Oil or Water Tank Vessel Flow Control with Sensor
