1cavity 3-5L Pet Drink Bottle Semi-Automatic Blow/Blowing Molding Machine

Product Description

D-R805 3-5L One Cavity Semi-Automatic blow moulding machine
https://chinadoria.en.made-in-china.com/product-list-1.html
1. Model: D-R805
Description & Features:
D-R805 Stretch Blow Molding Machine is suitable to produce different shapes of PET/PP bottles/jars as well as PMMA globes(neck size below 100mm). It is applicable for blowing bottles from 3L to 5L and is widely used to produce mineral water, carbonated drink, juice, medicine, cosmetic and oil bottles etc.
The machine adopts revolving infrared pre-heat system. It ensures PET preforms be heated evenly.
The machine uses mechanical-double-arm mould clamping which ensures the mould will be closed tightly even under high pressure and high temperature.
The air system consists of two parts: pneumatic action part and bottle blow part to meet the different pressure requirements for the action and blowing. It can provide sufficient and steady high pressure for blowing large irregular shape bottles.
The machine is also equipped with silencer and oiling system to lubricate the mechanical parts of the machine.
The machine can be operated in the step-by-step mode and the semi-auto mode.
2. TECHNICAL SPECIFICATION

TYPE	ITEM	UNIT	TECHINICAL DATA
END PRODUCT	Material		PET/PP/PE/PC
	volume	L	3-5(1-cavity)
	theoretical output	pcs/hr	3-5L: 350-400
	Max. length	mm	360
	Max. diameter	mm	180
MOULDING	Max.mould plate dimension(L*H)	mm	420 X 500
	max thickness of mould	mm	240-400
	clamping force	KN	200
	mould opening stroke(adjustable)	mm	300
AUXILIARY	High air pressure compressor	M3 /Mpa	≥1.2/3.0*1set
	air filters	M3 /Mpa	≥1.0/3.0*2pcs
main machine electricity	power	KW	6
	voltage/frequency	V/HZ	220/380/50-60 (3-phase)
machine size and weight	Blower dimension (L*W*H)	M	1.53*0.6*2.0
	Blower weight	T	0.6
	Infrared- heater(L*W*H)	M	1.8*0.5*1.16
	Infrared- heater weight	T	0.3

3. Pictures of D-R801:
4. Frequently Asked Questions:
Q: Can I get free samples?
A: YES. We would like to send several samples for your reference if you could afford freight.
Q: What surface handing could you support?
A: We cab provide screen printing, hot stamping, frost, label printing etc.
As to printing color: Color can be made according to PANTONE color number.
Q: Do you accept customized order?
A: YES. We can arrange opening the mould according to customers' requirement.
Q: What is the normal lead time?
A: (1). For stock products, we will send goods to you within 12-24 hours after we receive your payment.
(2). For surface handing products, the delivery time is within 7-10 work days after we receive your payment.
(3). For products we never manufactured, we could open the mould if needed.
Q: What is your selection of shipping method?
A: (1). For small trial order, international express, just as TNT, DHL, FedEx, UPS, EMS is suitable.
(2). For large order, we can arrange shipment by sea or air according to your requirement.
5. About us:
Taizhou Doria Plastic Equipment Co., Ltd. is located the town of plastic products and mould in China, which is one manufacturer owns special production teams, advanced production equipments and rich production experience.
The main products are following: Automatic & semi-automatic blow moulding machine, PET preform, plastic injection machine, preform moulds, bottle moulds, commodity moulds and correlative products.
Based on "Quality is first; Honor for the honest", we always continue development and innovation to witness the maturity of industrial chain of products and improve the quality of products continually. Untiring effort makes the products, especially for 5gallon blow moulding machine, 5gallon PET preform and commodity moulds are widely accepted by our customers.
We have good market in South America, Africa, Asia, Europe, North America, and our many customers from Canada, Brazil, Thailand, Chile, Algeria etc.
Meanwhile, the output of our main product automatic 5gallon blow moulding machine could achieve 600pcs/h which is the breakthrough of our company.
Welcome everyone to visit us, we hope we will have good chance to cooperate!
