ATV UTV CTV Vs Belt Transmission Drive V Belt

Product Description

The variable-speed belt is an essential component in the power transmission of the all-terrain vehicle, which offers a reliable and efficient means of power transmission and is widely used in ATV, UTV, and CTV vehicles. These vehicles often need to travel in different terrains and environments, so a drive system that can adapt to different speeds and load requirements is needed. Therefore the SMSouth brand variable-speed belt is made from high-quality materials like CR rubber with aramid fiber and aramid cord, these belts ensure durability and longevity. Their unique cogged design allows for smooth engagement with the sprockets, enhancing torque transmission and load handling. Further increases in demand for the performance of drive elements and the trend towards designing ever smaller, space-saving drive units, led to the development of the Double-sided, SMSouth brand Molded cogged Raw Edge Variable speed belts. Double-sided SMSouth brand variable speed belts allow for the smallest pulley diameters, even below standard recommendations. The Double-sided design improves heat emission, significantly reducing the belt running temperature. The production methods and the structure of the belt have been derived from the SMSouth brand Molded cogged Raw Edge Variable speed. Depending upon the application and application range, this belt can also be equipped with layers of special cross-cord material in the base compound. The belt is Double-sided, with the cogs' depth and spacing matching the specific belt profile. The polyester or aramid tension cord ensures ideal power transmission, increased service life, and extremely low-stretch characteristics. Variable-speed belts have the advantages of high efficiency, long life, and low maintenance costs, and can meet the power transmission needs of these vehicles under different conditions. With the continuous advancement of technology, variable-speed belts are also constantly being improved and optimized to adapt to more complex and harsh working environments.

Section: Black Fabric: Sheer Strength Polyamide with CR rubber with Aramid fiber . Tension cord: low-stretch poly cord or Aramid cord. Gear tooth core: durable polychloroprene-rubber compound with Aramid fiber Tooth Fabric: Sheer Strength Polyamide with CR rubber.

Product Benefits: High flexing capability Exact running performance Very long service life ATV belt for 400-1000CC belt available. Belt for Leopard, Viking, Grizzly, Taiga(A), Patrul 800, Odes 650/800/1000, Star, 500G/K, etc. Significant mute effect, relatively high transmission efficiency, high durability, maintenance-free, and improved driving quality

ITEM	OEM		MODEL
	Polaris	Dayco
POLARIS
1	3211113/3211116	XTX2239	500 ~ 800 cc
2	3211069/3211095	HP2002	Sportsman 500
3	3211123	XTX2244	850cc
4	3211130	XTX2248	Ranger 800 RZR S Scrambler XP 850 Sportsman Touring 850
5	3211133/3211162	XTX2250	Polaris Ranger 800
6	3211142	XTX2251	Ranger 900 RZR XP
7	3211148/3211149	XTX2252	Ranger 900 & RZR 1000
8	3211143	XTX2254	Ranger 570 RZR
9	3211135	XTX2256	Polaris Ranger Diesel UTVs
10	3211172	XTX2264	RZR 900
11	3211101	XTX2265	Ranger 650 TM
12	3211169	XTX2266	Ranger 570
13	3211160	XTX2268	Sports man 850 Scrambler850/1000
14	3211180	XTX2275	RZR 1000
15	3211186	XTX2276	rzr 1000 Turbo
16	3211106	XTX2249	Ranger 700 EFI Sportsman 800 EFI
17	3211196	XTX2279	general 1000 EPS
18	3211183		Axys 800 Pro RMK SKS
19	3211077/3211048	20G4022
20	3211091/3211095		DRIVE BELT FITS POLARIS
21	3211175
22	3211202		new turbo
GOLF
1	72054-G01, 72024-G01, 72025-G01		EZGO TXT Medalist
2	26414-G01
3	618630		E-Z-GO RXV
4	1016203		Club Car
5	1016203/101916701
6	J38-46241-00
7	JW1-G6241-10-00
8	1014081
9	J55-G6241-00
10	14153-G1
11	JW1-H1173
12	1017188 /101916701
13	GCB-20001
14	GCB-20002
15	GCB-20003
YAMAHA
1	5GH-17641-10-00	XTX2205	YFM400 450
	5GH-17641-00-00
2	5KM-17641-00-00	HPX2233 HP2033	YFM660 YXR660
	5KM-17641-01-00
3	5UH-17641-01-00	XTX2240	many 350cc ATV models.
4	3B4-17641-00-00	XTX2241	700CC
	5B4-17641-00-00
	B16-E7641-00-00
5	1XD-17641-00-00	XTX2260
6	4WV-17641-00-00	XTX2270
	4WV-17641-01-00
7	28P176410000	XTX2271
8	8DN-17641-01-00	XTX5033	FX NYTRO / RS /RX 1000CC
	8GS-17641-00
9	5RU176410000		Yamaha YP 400 x-max
10	5VU176410000		Yamaha XP 500 T-max
11	59C176410000		Yamaha XP 530
12	1SD-17641-00
13	25300-F68-0000		Double side
14	PN52-2187-C
15	23100-LEA7-E01		Kymco Downtown 300i / GTi30
CF MOTO
1	0800055000	40G3691	CF MOTO 800 CC
2	0180055000	40G3569	CF MOTO 500 CC
ARCTIC CAT
1	3402-757 / 3402-484	HP2032	500/XP 550 CC
2	0823-228	XTX2243	366/400/450/500 CC
3	0823-496	XTX2277	700cc +
4	0823-391	XTX2259	Wildcat
5	0627-046	XTX5032
6	0823-013	46G3569	TRV 550/ 600 /700,
7	0823-231	46G3596	Wild cat / TRV 1000cc
SKI-DOO
1	414-8607-00	39G4266	500 ~ 600 cc
2	417-300-391	XTX5034	800 cc
3	417-300-197	XTX5024	600 cc
4	417300189	XTX5041	1000 cc
5	417300383		DBSD383EX
KAWASIKI
1	59011-0040	XTX2282	Tery x4 800
2	59011-0003		KAWASIKI 650/700
3	59011-0037	XTX2280	KAF820 & 1000
4	59011-0011	XTX2257	KAF400 Mule 600
5	59011-0019	XTX2240	KRF750 Teryx 4x4
6	59011-1080	XTX2217	KVF360 Prairie
7	59011-1087
8	59011-1084
BOMBARDIER
1	715900030/715000302	XTX2236	800 & 1000 cc
2	715900023	XTX2274	500 / 650 cc
3	417300383	XTX5034	HD10/ X3
4	715900024	26G3628	Outlander 400cc

Application:

Our Motorcycle belts are suit of ATV, UTV and CTV vechile, suc as the following famous brand:POLARIS, GOLF, YAMAHA, CF MOTO,ARCTIC CAT, SKI-DOO,KAWASIKI,BOMBARDIER,Buyang, Bashan, Baja, Carter Brothers, Dinli, EGL, Shineray, Hisun, Kandi, Kazuma, Massimo, Sunl, etc.

SERVICE: 1. New products can be developed on customers' samples or drawings.
2. Our factory provides OEM service if customers need it.
3. Free samples can be sent for customers to check the quality before ordering(if we have them in stock).
4. Logo accepted(advanced technology and equipments)
5. Other engine part products: V belt, cylinder head gasket, intake & exhaust valves, crankshaft, camshaft.
