Kingto Automatic Drum Filter for Aquaculture Water & Landscape Pond Water Filtration

Product Description

Product Description
Principle
The automatic drum filter(HDF series), is made in China with advanced German technology, is a low-energy mechanical filter. Its principle is that after polluted water flows into the drum, suspended solid larger than filter perforations in the water will be retained in the drum by the micro mesh and discharged by the sewage pipe. The polluted water flowing through the micro mesh is purified and then flows out of this micro-filter system.
Advantage1. The tank and cover are made of corrosion resistant and UV resistant German PEHD plate, with long life.
2. Built-in bypass, no need to interrupt water circulation in case of emergency, no need to install an external bypass pipeline.
3. The gear is made of corrosion resistant and high hardness material with low maintenance.
4. Siemens PLC or Omron timer, automatic flushing.
5. Suitable for aquaculture, landscape fish pond, aquarium engineering, fresh water and seawater can be usedTechnical dataFiltration: 30μ-90μ(as standard)
Filter surface: Max. 2.7m2
Max capacity:up to 225m3/h(at 60μ,SS≤10mg/l)
Scope of applicationSuitable for recirculating aquaculture systems (fresh water and seawater)landscape water treatment systems and industrial wastewater treatment system
Product Parameters

Product model	Flow (m³/h)	Overall size (mm)	Weight (kg)	Backwash pump power (kw)	Reducer power(kw)
HDF-20	32	990*967*840	83	0.75	0.15
HDF40	50	1070*1064*840	111	0.75	0.15
HDF60	90	1306*1222*860	161	0.75	0.15
HDF100	115	1630*1080*860	182	1.1	0.15
HDF150	150	1892*1080*860	202	1.1	0.15
HDF200	225	2122*1313*1075	300	1.5	0.15

Solution
Main Products
Company Profile
Why Choose Us
Packaging & Shipping
FAQ Q: What are your factory's main products?
A: We are focused on aquaculture equipment production. The main products are Automatic Drum Filter, Automatic Bait-throwing Machine, UV Sterilizing Device, Fish Tank and Other RAS Devices.
We can supply the overall solution of RAS fish farm, including project consulting, design, construction, RAS equipment and maintenance services.
Q: What is your product warranty?
A: The warranty is 12 months while the lifetime is 10-15 years under good maintenance. It is durable and anti-corrosion.
Q: How to get an accurate quote?
A: Please provide the following informations
Freshwater or seawater.
Model or Filtration & Filtration Capacity.
Port of the project.
Q: What is the payment term?
A: Our payment is T/T , 60% deposit, and 40% balance payment before shipment.
Q: We haven't imported before, can you ship the goods to our warehouse?
A: Yes. Although our normal trade term is EXW, FOB, CIF, we can also arrange logistics to your warehouse.
Q: How to assemble the equipment once we receive it?
A: The CAD install instruction, assembly procedure and project case will be provided., Of course our skilled installation engineers
would go to your country and install the equipment if needed.
Q: What is your MOQ?
A: Normally, our MOQ is 1 set.
