China Xuzhou Manufacture Xe55u 5.7ton Excavator with 0.16m3 Bucket
Basic Info.
Model NO.
XE55U
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Grab Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1~0.5m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Operating Weight
5700kg
Rated Power
30.7kw
Emission Standard
Tier 4
Maximum Torque/Speed
159.8/ 1500n.M
Displacement
2.434L
Travel Speed
4.6/2.8km/H
Swing Speed
9.5r/Min
Bucket Digging Force
38.2kN
Arm Digging Force
25.7kN
Transport Package
Wooden
Specification
5855*1880*2610mm
Trademark
KOMATCO
Origin
China
Production Capacity
10000 Units/Year
Product Description
Product DescriptionChina Xuzhou Manufacture XE55U 5.7Ton Excavator with 0.16m3 Bucket
1. Engine that meets Euro V emission standards is highly reliable, environmentally friendly, and have lower fuel consumption.
2. Compact and Tailless design cooperates with boom swing function, which can adapt to the narrow space operation flexibly.
3. A set of high-pressure quick-change pipelines and two sets of flow-adjustable backup circuit can truly realize one machine with multiple functions.
4. Key electrical elements are arranged in new type electrical box, which makes daily maintenance more convenient.
Detailed Photos
Product Parameters
| Item | Unit | Parameters | |
| Model | Operating weight | Kg | 5700 |
| Bucket capacity | m³ | 0.16 | |
| Engine | Model | - | V2403 |
| No. of cylinders | - | 4 | |
| Rated power | kw/rpm | 31.2/2200 | |
| Maximum torque/speed | N.m | 159.8/1500 | |
| Displacement | L | 2.434 | |
| Main performance | Travel speed (H/L) | km/h | 4.6/2.8 |
| Swing speed | r/min | 9.5 | |
| Gradeability | ° | ≤35 | |
| Ground pressure | kPa | 32.0 | |
| Bucket digging force | kN | 44.5 | |
| Arm digging force | kN | 29.2 | |
| Maximum tractive force | kN | 52.8 | |
| Hydraulic system | Rated flow of main pump | L/min | 158.4 |
| Main safety valve pressure | Mpa | 30 | |
| Travel system pressure | Mpa | 30 | |
| Swing system pressure | Mpa | 24 | |
| Pilot system pressure | Mpa | 3.5 | |
| Oil capacity | Fuel tank capacity | L | 68 |
| Hydraulic tank capacity | L | 46 | |
| Engine oil capacity | L | 9.5 | |
| Appearance size | A Overall length | mm | 5340 |
| B Overall width | mm | 1960 | |
| C Overall height | mm | 2555 | |
| D Width of platform | mm | 1830 | |
| E Track length | mm | 2490 | |
| F Overall width of chassis | mm | 1960 | |
| G Track shoe width | mm | 400 | |
| H Wheel base of crawler | mm | 1990 | |
| I Track gauge | mm | 1560 | |
| J Counterweight clearance | mm | 637 | |
| K Minimum ground clearance | mm | 315 | |
| L Minimum tail swing radius | mm | 1040 | |
| M Track height | mm | 550 | |
| Working range | A Maximum digging height | mm | 5650 |
| B Maximum dumping height | mm | 4010 | |
| C Maximum digging depth | mm | 3640 | |
| D Maximum depth cut for 2240mm(8 ft) level bottom | mm | 3200 | |
| E Maximum vertical wall digging depth | mm | 2690 | |
| F Maximum digging radius | mm | 6110 | |
| G Minimum swing radius | mm | 2430 | |
| Standard | Length of boom | mm | 2850 |
| Length of arm | mm | 1570 | |
