Klt-D6ma-S5K3p3 V3.0 WiFi Camera 16MP S5K3p3 Mipi Interface Auto Focus Camera Module
| US$27.00-29.00 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
KLT-D6MA-S5K3P3 V3.0
HDMI Format
4632 X 3480
Kind
Autofocus Lens
Certification
RoHS
Feature
Mini Size
Sensor Size
1/3.1"
Transport Package
Anti-Static Bag in Box
Specification
17.60 x 9.40 mm
Trademark
KLT
Origin
China
Production Capacity
500000 Pieces
Product Description
16MP S5K3P3 MIPI Interface Auto Focus Camera ModuleModel No. KLT-D6MA-S5K3P3 V3.0| Camera Module No. | KLT-D6MA-S5K3P3 V3.0 |
| Resolution | 16MP |
| Image Sensor | S5K3P3 |
| Sensor Type | 1/3.1" |
| Pixel Size | 1.00 um x 1.00 um |
| EFL | 4.24 mm |
| F.NO | 2.20 |
| Pixel | 4632 x 3480 |
| View Angle | 78.4°(DFOV) 66.2°(HFOV) 51.6°(VFOV) |
| Lens Dimensions | 8.50 x 8.50 x 5.37 mm |
| Module Size | 17.60 x 9.40 mm |
| Module Type | Auto Focus |
| Interface | MIPI |
| Auto Focus VCM Driver IC | DW9714 |
| Lens Model | KLT-LENS-50065B5 |
| Lens Type | 650nm IR Cut |
| Operating Temperature | -30°C to +70°C |
| Mating Connector | OK-10F030-04 |
