Universal Hydraulic Radial Drilling Driller Machine (Model Z3050X16  Z3063X20)

Universal Hydraulic Radial Drilling Driller Machine (Model Z3050X16 Z3063X20)

US$8,000.00-15,000.00 1 set (MOQ)

Basic Info.

Model NO.
Z3063x20
Controlling Mode
Artificial
Number of Shaft
Convnetional Radial Drilling Machine
Hole Diameter
63mm
Automatic Grade
Semiautomatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Max. Drilling Dia.
63mm
Distance Between Spindle Centerline to C
630-2120mm
Spindle Travel
350mm
Spindle Taper
Morse 5#
Spindle Speed Range
25-2000rpm
Spindle Speed Step
16 Stpes
Spindle Feed Range
0.04-3.2mm/R
Worktable Size
630X500mm
Spindle Motor Power
5.5kw
Weight of Machine
6500kg
Transport Package
Polywooden Case
Specification
Overall size: 2880x1250x2915mm
Trademark
Dalian ZT Machinery
Origin
China
HS Code
8459290000
Production Capacity
100 Sets/Month

Product Description

The radial drilling machine is the universal machine for general purposes, and suitable for drilling, counter boring, reaming, spot facing and tapping on mediator Large sized parts. Boring is also possible where such technological equipment is available.
Features :
1. Their adoption of hydraulic pre-selected change speed mechanism saves setting time.
2. Such motions as the forward and reverse rotation of the spindle, braking, speed changing, as well as its neutral position are controlled
by a hand lever. This facilitates easy operation.
3. A hydraulic driven rhombic block clamping mechanism is adopted for the
spindle head , the arm, the inner and outer column, which ensures reliable clamping.
4. Upper guide way on the arm, circular surface of the outer column, spindle and
its sleeve as well as the rotary path of the inner outer columns have undergone hardening treatment, so that the ratability of the machine
accuracy is retained for along time and that the service lives of the machine are prolonged.
5. Complete safety device and outer column protective device are provided in these machines.
Model
Item
Unit Z3050×16/I Z3063×20/1
Max drilling diameter mm 50 63
Distance between spindle axis and column (min/max) mm 350/1600 450/2000
Distance between spindle axis and working surface of machine base (min/max) mm 320/1220 400/1600
Rang of spindle speed r/mm 25-2000 20-1600
Number of spindle speed No. 16 16
Rang of spindle feeds mm 0.04-3.2 0.04-3.2
Spindle taper(Mohs) No. 5# 5#
Number of spindle feeds No. 16 16
Spindle travel mm 315 400
Worktable dimensions mm 630×500 800×630×500
Horizontal mm 1250 1550
Max torque of spindle 980 980
Power of main motor kW 4 5.5
Distance of headstock horizontal movement mm 1250 800
Weight of the machine kg 3500 7000
Overall dimensions of the machine mm 2500x1070x2840 3080×1250×3205

Standard accessories:
Worktable 1 set
Foundation bolt 6 pcs
Reducing sleeve 4 pcs
Wedge 2 pcs

FAQ
1. MOQ
1 set
.
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.

3. PAYMENT TERM
T/T 30% down payment when order, 70% balance payment before shipment.
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.
