Manufacturer Made and Supply Directly Dt-185 18 Ton Middle Size Crawler Excavator for Sale

Product Description

Product Description

Giant excavator at work The DT-185 is a high-productivity, low-owning, and operating-cost excavator that will generate more prosperity for you and your business. Excellent working performance Find the power and durability you need in your excavator when you choose DT-185 which features fuel-efficient technology that can save as much as 10% on fuel costs. With DOOTEC's optimized positive flow hydraulic system that improves operating efficiency by 5%, you can get more work done in less time - and for less money - in even the toughest conditions with the DT-185 big excavator digging. Powerful, robust, and reliable powertrain & hydraulic components for long life in the most demanding applications. Optimized positive flow hydraulics improve operating efficiency by up to 5% and fuel efficiency by up to 10%.

Detailed Photos
Product Parameters

DT185	Engine
	Engine Model	/	Cummins
	Power	kw/rpm	110/2050
	Cooling Type	/	water Cooling
	Structure Weight	kg	18000
	Bucket Capacity	(m3)	0.28-0.75
	Length of Boom	mm	4600
	Length of Arm	mm	2500
	Buckect Type	/	backhoe
	Power	/	Traditional Power
	Hydraulics
	Main Pump Type	/	Variable displacement axial piston race pump
	Pump Steam	l/min	2×116
	Swing hydraulic motor type	/	26.5
	Working hydraulic oil circuit	Mpa	Standard 32.5/Boost 34.3
	Walking hydraulic circuit	Mpa	32.5
	Pilot pump flow	L/min	27.7
	Performance
	Swing Speed	rpm	12
	Walking Speed	km/h	3.4-4.9
	Bucket digging force	kN	Standard 77.4/Boost 81.3
	Arm Digging force	kN	Standard 57.8/Boost 62
	Dimension
	Total transport length	mm	7710
	Total transport Width	mm	2800
	Total transport height	mm	2830
	Cabin Height	mm	2830
	With of Upper Body	mm	2710
	Counterweight ground clearance	mm	920
	Track ground length	mm	2780
	Total track length	mm	3495
	Max. Digging Height	mm	8620
	Max.Unloading height	mm	6200
	Maximum vertical digging depth	mm	5070
	Maximum effective digging depth	mm	5380
	Width of Crawler	mm	600
	Overall track width	mm	2800
	Track Gauge	mm	2000
	Minimum ground clearance	mm	410
	Rear turning radius	mm	2200
	Working Range
	Max. Digging radius	mm	8260
	Max. Digging radius on Parking Level	mm	8110
	Max. Digging Depth	mm	5630

Hot Product
DT350 DT260 DT230

DT65 DT160 DT180
DW80 DW88 DW150
mini excavators:
WS-17 WS-18 WS-15
WS-13 WS-12 WS-08
Company Profile
Established in 2014, Wishope Machinery focus on construction & agricultural machinery products manufacturing and export for around 10 years. The R&D team has fully learned the design concepts of Japanese and Korean hydraulic excavators, with years of sales and modification, all the product design is very mature and stable. Over 250 employees and 22 senior engineers. We export small to big excavators to over 20 countries such as Indonesia, Malaysia, Colombia, and mini excavators exported to the USA and to European countries.Wishope Hydraulic Excavators - innovative construction machinery: Digging, excavating and shoveling are the main tasks of the excavator. Whether in civil engineering digging a pit or dredging in a body of water: Our hydraulic excavator offers the optimum machine for every task.Get an overview of all micro excavators and find the right construction machine for your application. A wide range of attachments are available for our machines. Excavator buckets and shovels, vibrators and hammers, and grabs make your excavator a real working machine.China's excavators are growing at a high annual export sales rate of about 15% in the past 3 years. There are big Chinese excavator like our Dootech. After decades of technological precipitation, Chinese excavators have been able to find a balance between price and quality in a very balanced manner, so as to achieve high export sales.
Packaging & Shipping
Our Advantages
What Kinds of Excavators We Can Provide?Hydraulic excavators are divided into many types according to the tonnage of the model. 1-3 tons are called micro excavators, 6-13 tons are called small excavators, 15-39 tons are called MIDI excavators, and more than 40 tons are called large-scale excavators.We can provide all kinds of crawler excavators, including Dootech brand with Korean technology, mini long-reach excavators with Japanese technology, etc.At the same time, we also customized accessories, such as the modification of long arms, OEM amphibious excavators, and the modification of excavator attachments, the spare parts of various brands of excavators.
FAQ
1.How deep can a 6-ton excavator dig?
A 6 ton excavator is a versatile piece of machinery that is commonly used in construction and excavation projects. With its powerful engine and hydraulic system, a 6-ton excavator can dig to a depth of approximately 10-12 feet (3-3.6 meters). Its size and weight make it ideal for digging trenches, foundations, and utility lines.
The excavator's reach and digging depth are also influenced by the length and type of its arm and bucket. In addition, the type of soil and terrain also play a role in determining how deep the excavator can dig. Overall, a 6 ton excavator is a reliable and efficient machine for various excavation tasks, and its digging capabilities make it a valuable asset in construction projects.
2.What attachments are available for a 15 ton excavator?
DT-160 is a multifunctional machine that is widely used in construction as well as in the farming industry. More and more clients worldwide have delivered versatility with many attachments.
DT-160 can perform various tasks like digging, lifting, and drilling with an auger, grapple, forklift, and hydraulic breaker. The bucket attachment serves as a default configuration. You may request a different attachment, as we provide OEM solutions for you.
3.Can you provide OEM/ODM excavator service?
Dootec is an OEM/ODM excavation machine manufacturer and supplier. Suppose you need to customize the core parts or the entire machine. Our professional technical support is everything you need! We can also help you print brand logos and paint different colors.
4.How many tons is a standard excavator?
A typical standard excavator will weigh 19-24 tons, but they can range from 10 to 45 tons. Unlike smaller sizes, standard excavators are fitted with treads instead of wheels, making them good at navigating rough terrain.
5.How far can a long grapple excavator reach?

Bigger excavators can reach from 20 to 30 feet along the ground with 25 feet being the average distance. Long-reach excavators usually reach from 30 to 60 feet out. The 60-foot reach is the standard size long reach excavator. Specialized long-reach excavators (not typically available) can reach 70 to over 100 feet.
6.What do the tonnes of an excavator mean?
Excavators are known for their tonnes, which corresponds to their operating weight. For example, 23 tonnes of excavators' operating weight is 230,000kg. Depending on user preferences and needs, different attachments can be matched with the excavator, Make sure to read specifications and manuals to better understand its associated maximum capacity.
