Dawson As4497 Wll 6ton 6000kg Polyester Endless Round Lifting Slings

Product Description

DAWSON AS4497 WLL 6Ton 6000KG Polyester Endless Round Lifting Slings


When ordering it is important to make clear whether the length specified is circumference or effective working length.
Material: 100% high-strength polyester yarn
Safety Factor:6:1 7:1 8:1
Standard: ISO: ISO4878
European: EN1492-2:2000
Australian: AS 4497

	Item	Color coded according to EN1492-2	Working Load Limit with 1 round sling							Working Load Limit with 2 round slings
			Straight lift	Chocked lift	0-7					Straight lift up to 45	Choked lift up to 45	Straight lift 45-60	Choked lift 45-60
						0-7	7-45	45-60	45-60
			1.0	0.8	2.0	1.4	1.0	0.7	0.5	1.4	1.12	1.0	0.8
	DSRES-1T	WLL1T	1.000	800	2.000	1.400	1.000	700	500	1.400	1.120	1.000	800
	DSRES-2T	WLL 2T	2.000	1.600	4.000	2.800	2.000	1.400	1.000	2.800	2.240	2.000	1.600
	DSRES-3T	WLL 3T	3.000	2.400	6.000	4.200	3.000	2.100	1.500	4.200	3.360	3.000	2.400
	DSRES-4T	WLL 4T	4.000	3.200	8.000	5.600	4.000	2.800	2.000	5.600	4.480	4.000	3.200
	DSRES-5T	WLL 5T	5.000	4.000	10.000	7.000	5.000	3.500	2.500	7.000	5.600	5.000	4.000
	DSRES-6T	WLL 6T	6.000	4.800	12.000	8.400	6.000	4.200	3.000	8.400	6.720	6.000	4.800
	DSRES-8T	WLL 8T	8.000	6.400	16.000	11.200	8.000	5.600	4.000	11.200	8.960	8.000	6.400
	DSRES-10T	WLL 10T	10.000	8.000	20.000	14.000	10.000	7.000	5.000	14.000	11.200	10.000	8.000
	DSRES-12T	WLL 12T	12.000	9.600	24.000	16.800	12.000	8.400	6.000	16.800	13.400	12.000	9.600

Code	W.L.L.	Color	Diameter	Min. length	Max. length
Tons			mm	m	m
DSRES-1T	1.0		19	0.5	80
DSRES-2T	2.0		25	0.5	80
DSRES-3T	3.0		28	0.5	80
DSRES-4T	4.0		32	0.5	80
DSRES-5T	5.0		36	0.5	80
DSRES-6T	6.0		38	1.0	80
DSRES-8T	8.0		43	1.0	80
DSRES-10T	10.0		48	2.0	80
DSRES-12T	12.0		53	2.0	80
DSRES-15T	15.0		60	2.0	80
DSRES-20T	20.0		70	2.0	80
DSRES-30T	30.0		86	2.0	80
DSRES-50T	50.0		119	2.0	80
DSRES-100T	100.0		140	2.0	80
DSRES-300T	300.0		280	2.0	80
DSRES-500T	500.0		350	2.5	80
DSRES-800T	800.0		426	2.5	80
DSRES-1000T	1000.0		476	3.0	80
