US$500.00-3,000.00
|
1 sets
(MOQ)
|
Basic Info.
Model NO.
VH14/20/30/50/100/200/300/400/500/600/800/1000
Application
Granules, Powder
Application Area
Pharmaceutical
Control System
Button Control
Main Material
Stainless Steel
Speed Control
Single Speed
Temperature Control
Without Heating
Material Processed
Chemicals, Food
Warranty of Core Components
1 Year
Key Selling Points
Automatic
Core Components
Motor, Gearbox
Voltage(V)
110V, 220V, 380V
Operating Type
Cycle Operating
Transport Package
Export Wooden Case
Trademark
Jincheng Merchinery
Production Capacity
15 Set/Sets Per Month
Packaging & Delivery
Package Size
171.00cm * 83.50cm * 173.00cm
Package Gross Weight
340.000kg
Product Description
Model | Barrel volume(L) | Working volume(L) | Rotating speed(r/min) | Overall size(mm) | Power(KW) | Net weight(kg) |
VH3 | 3 | 1.2 | 0-60 | 590*285*480 | 0.06 | 13 |
VH6~VH14
Model | Barrel volume(L) | Working volume(L) | Rotating speed(r/min) | Overall size(mm) | Power(KW) | Net weight(kg) |
VH6 | 6 | 2.4 | 24 | 650*305*720 | 0.37 | 36 |
VH10 | 10 | 4 | 24 | 710*325*700 | 0.37 | 48 |
VH14 | 14 | 5.6 | 28 | 820*365*840 | 0.55 | 52 |
Model | Barrel volume(L) | Working volume(L) | Rotating speed(r/min) | Overall size(mm) | Power (KW) | Net weight(kg) |
VH14 | 14 | 5.6 | 28 | 930*375*920 | 0.55 | 72 |
VH20 | 20 | 8 | 28 | 1000*420*880 | 0.55 | 82 |
VH30 | 30 | 12 | 23 | 1120*405*1050 | 0.75 | 94 |
VH50 | 50 | 20 | 20 | 1300*460*1200 | 1.1 | 150 |
VH100 | 100 | 40 | 18 | 1560*705*1500 | 1.5 | 180 |
VH200 | 200 | 80 | 15 | 1965*860*1750 | 1.5 | 300 |
VH300 | 300 | 120 | 13 | 2220*920*1950 | 2.2 | 520 |
VH500 | 500 | 200 | 12 | 2660*1250*2400 | 2.2 | 600 |
VH1000 | 1000 | 400 | 12 | 3220*1500*2840 | 6.6 | 1000 |
FAQ How to Order
1. Customer send us an inquiry.
2. Confirmmachine type, order quantity, price, lead time, payment term etc.
3.Our sales send the Proforma Invoice with company seal.
4. Customer make the payment for deposit and send us Bank receipt.
5. Inform the clients that we have got the payment,and will arrange the production according to yourrequest, inform the estimated time
6. Production products photos will send to you for approval.
7. Clients make payment for balance and Ship the goods .
8. Order is finished when you receive the goods and satisfy with them .
9. Feedback to us boutQuality , Service, Market Feedback & Suggestion.And we can do better
About after sell service
Usually machine guarantee time is about 1 year . Within guarantee time . Machine breaking caused bymachine itself design defect , we are responsible for it .we can provided free charge breaking part .If machine breaking caused by humane factor , user need take responsibility for it , we will providedtechnical support .
About goods shipping
We have long time working shipping forwarder. We can do our best to send machine to your port safe and quickly.
About our online Service
24 hours online to solve any problem .
Your email will be reply within 12 hours .
Your satisfy is our pursuit .sincerely hope our cooperation
