Customized Working Size Five Axis CNC Router Machine Carving Car Foamstyro Foam Wood Metal CNC Machine The Mold Processing Center Manufacturer Aerospace

Product Description

Product Description
1,Application :
The equipment is suitable for heterosexuality, three-dimensional cutting and engraving, drilling, milling, slotting, focusing on five-axis machining centers, and is widely used in thick film blisters, refrigerator liners, chassis shells, wood molds, plaster molds, lost foam, electrical equipment shells , medical equipment shells, plastic bags, bent wood and so on.
Detail machine pictures, all photoes are for 100% real shooting ! For more pictures, video and details, please email me!
1, Product Show
2, Specification

Machine Body	Steel plate + square pass integrated welding (the latest model)
rack	Precision ground rack
guide	Jiangmen Kate Rails
screw	Taiwan TBI screw
Spindle	12KW
Y axis	2 piece independent Y axis
Lubrication system	Automatic oil pump system
Control System	Five-axis linkage special (with RTCP) Lenark LYNUC
System control method	Bus absolute value
Processing file format	NC
Programming software	MASTERCAM/UG/POWERMIL
Y axis transmission mode	Inovance 0.85KW absolute servo drive + grinding rack drive
Z axis transmission mode	Inovance 1.8KW absolute servo drive + grinding rack drive
X axis transmission mode	Inovance 1.8KW absolute servo drive + grinding rack drive
A ,C axis transmission mode	Inovance 0.75KW absolute servo drive + Japanese reducer
Pneumatic Components	Yadek
Tool changer	8 sets knifes
Tool changer function	Have
Inverter	Fuling 15KW inverter
Workbench accessories	Standard 4 sets of N-150 suction cups
Electric box	Schneide r electrical components
Working table size	(L*W)1200mm*1200mmX2
Gantry height	900MM
Effective work height	750mm
X,Y,Z axis max speed	50m/min
X,Y,Za xis max working speed	20m/min
maximum turning speed	15m/min
Precision	±0.02mm
Repeatability	±0.05mm
Air pressure	6Mpa
Voltage	415V 50hz 3phase
Machine size	4300mm*2300mm*3800mm
Weight	3500KG

3 Detail Show
4, Samples Show:
5, Other Related Machines:
6, Usage
