Jwell Automatic Precision Blow Molding Machine for Disposable Plastic Medical Straws, Droppers, Pipette Tubes, Laboratory Tubes

Product Description

Product Parameters

Model	Unit	BM02D
Max product volume	L	2
Dry cycle	Pc/h	900*2
Die head structure	Continuous type	Continuous type
Main screw diameter	mm	65
Max plasticizing capacity(PE)	kg/h	70
Driving motor	KW	22
Oil pump motor power(Servo)	KW	11
Clamping force	KN	40
Space between platen	mm	138-368
Platen size W*H	mm	286*330
Max.mould size	mm	300*350
Heating power of die head	KW	6
Machine dimension L*W*H	m	3.0*1.9*2.4
Machine weight	T	5
Total power	Kw	45

Detailed Photos

Product Description
Product Features: Versatile Production: Supports manufacturing of 100ml-3000ml milk bottles, soy sauce bottles, and yellow wine bottles, as well as 200ml-5000ml shampoo bottles, body wash bottles, detergent bottles, and children's toys. Advanced Co-Extrusion: Optional pearly lustre layer co-extrusion system for premium finishes. Flexible Die Head Options: Customizable cavity selection to match various product sizes. Hydraulic Efficiency: Optional JW-DB single-station hydraulic screen-exchanger system for smooth operation with different materials. Automated Operations: Available features include auto-deflashing, scrap conveying, and finished product conveying for efficient, streamlined production. Product Description: The JWZ-02D/05D/12D/20D Double Station Blow Molding Machine is engineered for precision and efficiency, making it ideal for producing a wide range of plastic bottles and children's toys. Its high-performance double-station design enables rapid production of containers ranging from 100ml to 5000ml. The machine supports optional pearly lustre co-extrusion to create visually striking finishes, catering to premium packaging needs. It also offers tailored die head cavities to accommodate varying product sizes and a hydraulic screen-exchanger system to handle diverse material requirements.
This blow molding machine is equipped with automation options such as auto-deflashing and scrap conveying, ensuring seamless and cost-effective production processes for manufacturers.
Product Application: Beverage Packaging: Milk bottles, soy sauce bottles, yellow wine bottles. Toiletries: Shampoo bottles, body wash containers, detergent bottles. Toys: Durable and customizable plastic toys for children. Premium Packaging: Pearly lustre layer co-extruded products for high-end applications. Custom Requirements: Products with unique shapes or material specifications for various industries. Company Profile
