Liugong 22ton Crawler Excavator Clg922e Hydraulic Excavator with 1.0m3 Bucket in Stock
Basic Info.
Model NO.
CLG922E
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Operating Weight
22000kg
Standard Bucket Capacity
1.0m³
Engine Model
6btaa5.9-C150-II
Rated Power
112kw @1950rpm
Emission
Stage II
Number of Cylinders
6
Displacement
5.9L
Arm Digging Force
105 kN
Bucket Digging Force
152.5 kN
Shoe Width
600 mm
Boom Length
5710mm
Arm Length
2915mm
Maximum Travel Speed
5.7 Km/H
Drawbar Pull
220kN
Fuel Tank
420L
Transport Package
Nude Packing
Specification
9540*2990*3140mm
Trademark
Famous brand
Origin
Guangxi, China
HS Code
8429521200
Production Capacity
5000 Pieces/Year
Product Description
Hot Sales 22Ton Crawler Excavator CLG922EProduct Description
* Unmatched performance driven by the Cum---mins Engine enhances torque output with more power and breakout force at lower engine speeds.
* Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.
* Ergonomically designed cab for LiuGong E series excavator, with great visibility, expansive room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide most comfortable working environment.
* Hydraulic request signals detect activity, decreasing and increasing engine speed as required. Power is supplied only as needed, achieving optimum fuel efficiency.
*Outstanding stability and durability come from an X-type reinforced frame and the long track beam and crawler system
Product Parameters
| Operating weight | 22000 kg |
| Engine power | 112 kW (150 hp) @ 1950 rpm |
| Bucket capacity | 0.9 / 0.95 / 1.0 / 1.1 / 1.2 m³ |
| Maximum travel speed (High) | 5.7 km/h |
| Maximum travel speed (Low) | 3.3 km/h |
| Maximum swing speed | 12.5 rpm |
| Arm breakout force | 97 kN |
| Arm breakout force Power boost | 105 kN |
| Bucket breakout force | 140 kN |
| Bucket breakout force Power boost | 152.5 kN |
| Shipping length | 9540 mm |
| Shipping width | 2990 mm |
| Shipping height | 3140 mm |
| Track shoe width (std) | 600 mm |
| Boom | 5710 mm |
| Arm | 2915 mm |
| Digging reach | 9870 mm |
| Digging reach on ground | 9685 mm |
| Digging depth | 6562 mm |
| Vertical wall digging depth | 5080 mm |
| Cutting height | 9945 mm |
| Dumping height | 7170 mm |
| Minimum front swing radius | 3090 mm |
| Model | Cum-mins 6BTAA5.9-C150-II |
| Emission | EPA Tier 2 / EU Stage II |
| System maximum flow | 2×224 L/min (2x59 gal/min) |
| System pressure | 34.3 MPa |
Detailed Photos
