China Hydraulic Bottle Lift Supplier 50 Tons Hand Tool Vertical Car Jack

Product Description

Product Description
Model: 5 tons vertical car jack hydraulic jacks

Cappacity	5 tons
Lifting Height	110mm
Adjustable height	60mm
Min height	185mm
Max height	355mm
Piston dia	3.2cm
Body dia	7.0cm
Base size	9.8*10cm
Hand rod length	31cm
Weight	4.8kg

The other data see the table:

Model	Lifting Wt(ton)	Min.h (mm)	Lifting H(mm)	Aduust H(mm)	Max H(mm)	Net Wt(kg)	20'Container (pcs)	Measurement (cm)	quantity (pcs)	GR.Wt. (kg)
ZW0203B	2	181	116	48	345	2.7	6150	52*25.5*21	10	28
ZW0403B	4	194	118	60	372	3.3	5000	46*26.5*22.5	8	29
ZW0603B	6	216	127	70	413	4.5	3670	37*27.5*22.5	6	29
ZW0803B	8	230	147	80	457	6	2750	29.5*27.5*26.5	4	26
ZW1003B	10	230	150	80	460	6.6	2500	29.5*28.5*26.5	4	28
ZW1203B	12	230	155	80	465	7.8	2120	29.5*17.5*26.5	2	18
ZW1603B	16	230	150	80	460	8.6	1920	31.5*17.5*26.5	2	20
ZW2003B	20	242	150	60	452	11	1500	34.5*19.5*27	2	24
ZW3003B	30	240	130	/	370	21	800	19.5*18*27	1	22
ZW5003B	50	236	120	/	356	30	560	24*22*27	1	31

Detailed Photos

Company Profile
Jiaxing Zhongwan Import&Export Co. Ltd. Is located in Jiaxing City which is the center city of the most prosperous and dynamic Economic Circl in China --Yangtze River Delta. It cannot be ignored about highly convenient transportation system of Jiaxing City. You can go everywhere in China through the highway and three big airports around Jiaxing enable you to fly all over the world.
In addition, several mutifunctional seaports along the coast of Jiaxing City qualify us to do world trade without tranpotation problem. There is only one hour away to go to Shanghai metropolis by car. Hangzhou and Suzhou are also an hour away from Jiaxing. This represents our company's place utility that will down the transport expenses to the loweset level.
We are engaged in the import and export of goods and technology business mainly. The strengths of our companies operates:Hydraulic Jack,Bottle Jack, Floor Jack, Trolley Jack, Scissor Jack, Jack Stand etc.


FAQ
Q1. Are You a Trade Company or a Manufacturer?
A: We Are Jack professional supplier include hydraulic jack ,Bottle Jack, Floor Jack, Trolley Jack, Scissor Jack, Jack Stand etc
Q2. May I Make Mix Order?,
Yes, You Can Make Mix Order Under Our MOQ.
Q3. What Is Your Terms of Payment?
A: T/T In Advance, L/C At Sight, 30% Deposits/ 70% Balance Before Delivery. We'Ll Show You The Photos of The Products And Packages Before You Pay The Balance.
Q4. What Is Your Terms of Delivery?
A: Exw, Fob, Cfr, Cif.
Q5. How About Your Delivery Time?
A: Generally, It Will Take 15 To 30 Days After Receiving Your Advance Payment. The Specific Delivery Time Depends On The Items And The Quantity Of Your Order.
Q6. What Is Your Sample Policy?
A: Paid Sample with Freight Collect.
Q7. Do You Test All Your Goods Before Delivery?
A: Yes, We Have 100% Test Before Delivery
