Water Ring Waste PP/PE/HDPE/LDPE Flake/Scrap Agriculture Film Woven/Raffia/Cement/Shopping Bag Recycling Plastic Pellet/Granule Granulator Machine

Product Description

Water Ring Waste PP/PE/HDPE/LDPE Flake/Scrap Agriculture Film Woven/Raffia/Cement/Shopping Bag Recycling Plastic Pellet/Granule Granulator Machine
In order to better give you professional answers, when sending the inquiry, please describe your parameters or technical requirements (such as: processing materials, output size, capacity, etc.) and attach your contact information (such as phone number, e-mail, facebook, whatsapp, wechat, etc.)
Applications:
Double Stage PP PE Plastic Film Woven Bag Plastic Granulating Line is double stage plastic regenerative pelletizer, which is suitable for many kinds of plastic waste materials recycling and making pellets, such as PE, HDPE, LDPE, PP, BOPP plastic film, bag,fiber,rope scrap material and etc. The film can be pressed in the compressor and then be pelletized.
1.Applicable plastic materials: PE, HDPE, LDPE, PP, BOPP, PET, PA/Nylon, etc.
2.Material shapes: film, bag,fiber,rope scrap.
3.Material types: rolls, loose, bundled.
4.Material comes from offcut, industry defective materials, washed materials and printed materials.
Note: depending on different material properties, various downstream equipments are needed.
Product Description:
This water-cooling single screw plastic pellet making machine is one stage plastic regenerative pelletizer, which is suitable for many kinds plastic waste materials recycling and making pellet, such as PP, HDPE, LDPE, LLDPE Film and clean woven/nonwoven bag materials, etc. The film can be pressed in compressor and then be pelletized.
Process Flow:
Conveying feeding→Metal detector→Film agglomerating→Degassing single screw extruder→Hydraulic stainer exchanger→Rub sufface granulating machine→Slip trough→Dewatering machine→Librating screener→Blowing system→Storage hooper→Finished product packing.
Detailed description of each item:
1. Conveyor: convey PP PE film or flakes into the compactor.
2. PE film Agglomerator /Compactor: crushing and compress film, and feed compressed film into extruder forced, to make the production capacity high and stable.
3.1# Extruding system: plasticizing material and exhausting gas.
4. 1# High-speed Net exchanging system: filter material impurity, to make production more stable.
5. 2# Extruding system: plasticizing material.
6. 2# High-speed Net exchanging system and Die-head: Second filter material impurity, to make production more stable.
7. Water ring pelletizing machine: cutting pellets in water.
8. Water tank: cooling pellets.
9. Dewater machine: make pellets dry.
10.Vibration sieve: remove bad pellet and keep good pellet.
11. Air Blower: convey good pellets into silo.
12. Storage silo: keep pellet.
Components:
Features:
1. Allow free assembling of the screw component, based on raw material type.
2. Using the suitable die head for palletizing, such as water ring cutting, under-water cutting and hot face cutting.
3. High efficient force feeder ensures stable high capacity material feeding, low power consumption.
4. Main screw has vacuum exhaustion.
5. Water ring granulator machine, attached with dryer. 6. Single screw extruder, with specially designed screw, barrel, venting system, ensure the good quality of the final products.
7. Pelletizing style: standard cutting with extrusion mould. Even cutting ensures with good shape.
Equipment List

No.
1	Belt conveyer
2	Crushing barrel
3	Extruder
4	Die head and screen changing device
5	Water ring cutter
6	Vibrating screen
7	Vertical dewatering machine
8	Air drying system
9	Cyclone hopper

Technical Parameters:

Model	PNHS-100	PNHS-200	PNHS-300	PNHS-500	PNHS-600	PNHS-800
Volum(L)	100	200	300	500	600	800
Output(kg/h)	100	150	200	300	400	550
Fixed and Rotating Blades QTY	2+6	2+6	4+8	4+8	4+8	4+8
Main Motor(kw)	37	55	75	90	90-110	132

FAQ
1, Are you a trading company or manufacturer?
A: WANROOETECH is a Factory-Outlet Platform for excellent manufacturers only!
2, As the shipping period, will take a long time, how can you make sure the machine won't be broken?
A: Our machine is film wrapped, to make sure the machine can be delivered to our customer smoothly, we will use the steel wire to fix the machine with the container.

3, I am a foreign customer, if the product's part is broken, how can get help from you?
A: Some standard configurations you can buy in your local market, such as SIEMENS Motor.

4, Could I know the process of manufacturing production after placing the order?
A: Our sales will share the video after testing, or take online video when testing the machine. Of course, also welcome you to our factory to see machine testing.

5, Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings according to the quantity.

6, Where is your factory located? How can I visit there?
A: Our company is located in Zhangjiagang City, China, really glad to invite you to come to our office to have a face to face meeting before we build to order.

7, We are new buyers, do not know how to buy? Can we use our own freight forwarding?
A: We are a very experienced company, we will provide you with the guidance of security. We have long-term freight forwarders partners to ensure the delivery of goods to various countries for our customers. You can use your freight forwarding.
Our Service
1. One year guarantee for the whole machine.
2. 24 hours technical support.
3. Our engineers can provide service overseas. The service is free, but the charge of round air-tickets, food, and the hotel is to the customer's account.
4. After a year, we can instruct you how to maintain the machine, and spare parts are provided with the best price.
5. We also can provide training service which help operators handle the machine well.
