Concrete Crusher, Demolition Pulverizer, Hydraulic Double Cylinder Shear for All Excavators

Product Description

Product Description
YTCT Factory Goods Features
Pulverizer Main Features: 1). Non rotation & 360° rotation available;
2). Equipped with German-made M+S motor, more powerful and stable.
3). Using HARDOX400-500 steel for shears.
4). Special cylinder design.
Product Parameters

Category	Unit	YTCT-mini	YTCT-02	YTCT-06	YTCT-08	YTCT-10
A	mm	300	450	800	1100	1100
B	mm	835	1465	1800	2200	2400
F1 Crushing force	ton	18	34	64	84	92
F2 Crushing force	ton	25	51	99	127	142
F3 Crushing force	ton	65	141	249	300	350
Oil pressure	Mpa	21	20-25	25-30	25-30	25-30
Excavator weight	ton	1.5-3	5-10	12-17	18-27	28-38
Weight	kg	200-210	600-650	1200-1500	1800-2000	2500-2800
Round steel	mm	14	16	25	30	35
♥ The Specifications of this equipment are subject to change for improvements. Excellent performance with high durability. The company has been developed to meet with the high standards of the current market.The demand for high durability and low maintenance costs on hydraulic equipment are combined in the total design of our attachments.

Detailed Photos
1. The main structure of the double cylinder shear is made of Swedish welded 400 wear-resistant plate.
2. The pin shaft is made of 42CrMo alloy steel with high strength and good toughness.
3. The oil cylinder adopts rolling technology and imported NSK oil seal, which is lightweight and has a long service life.
4. The blade is made of wear-resistant alloy steel, which is resistant to high temperature and deformation.
5. Plunger rotary motor, using vertical brake system, driven by self-protection hydraulic motor, capable of 360 degree rotation, equipped with customized balance valve to fix the scissor angle.
6. Small in size and more flexible, the dual cylinder ensures strong shear force, and high dismantling and shearing of steel bars in iron cans are more advantageous.
7. Detachable blade and jaw plate.

Installation Instructions
The hydraulic shear of the excavator can rotate 360 degrees hydraulically, improving the working ability;
Hydraulic crushing shears are mainly used for housing demolition, crushing, cutting various metal materials, and disaster relief and rescue applications. Their main characteristics are easy to work, not damage to excavators, and low working noise.
Hydraulic shears are divided into fixed type, mechanical rotary type, and 360 degree hydraulic automatic rotation. Different types of hydraulic shears can be produced according to different customer needs.
