| Project | Technical parameters | |
| Lens wide angle | 170° | |
| Storage capacity | Built-in 16 G/32G/64G/128G | |
| Screen size | 2-inch LED HD Display | |
| native playback | Support (live playback of video/photo/recording files) | |
| Segmented video | Support (multiple time segmentation video can be set) | |
| Key markers | Support (one-click mark key video during video shooting) | |
| Password protection | Support (software password protection, tamper-proof, anti-delete) | |
| Logging function | Support (all files are attached time, product number, user number and other information) | |
| Mobile detection | Support (picture object moving, automatically turn on video mode | |
| Voice broadcast | Support (boot user number) | |
| Vehicle mode | Support: use of CarLog with dedicated vehicle suction cup | |
| Alarm function | Support (long press menu key to display alarm sound and alarm flash | |
| Lighting | Support (available for night lighting and lighting | |
| Video Function | Video format | MOV/MP4/AVI( Customizable) |
| Video resolution | 2340*1296 1920*1080 1280*720 | |
| Video function | Press the "Video" button directly to enter the video state | |
| Circulating video | Support (when memory is full, the system automatically deletes the previous recording and continues recording) | |
| Video capture | Support | |
| Fast forward | 1-8x fast forward | |
| Pre-recorded / extended | Support (up to 40 seconds pre-recorded, extended can be set) | |
| Photo photo Function | Photo format | JPEG( Customizable) |
| Anti-shake function | Optical anti-shake | |
| Exposure mode | Automatic | |
| Recording Function | Audio format | WAV( Customizable) |
| One click recording | Support for individual recording, dual Mike noise prevention | |
| Infrared | Infrared Night Vision | 15 meters to see the body |
| Infrared switching | Automatic switching (also manual switching) | |
| Battery | Battery capacity | Built-in 3100 mAh rechargeable polymer battery |
| Video time | About 10 hours | |
| Charge time | ≤3 hours | |
| Appearance Structure | Weight | 165 g |
| Appearance dimensions | mm 94*61*32 | |
| Protection level | IP68 | |
| Drop resistance | 2.5 m | |
| Working ambient temperature | -30ºC-55ºC | |
| Interface | AVIN AVOUT input and output interface, USB data charging interface, Apple interface | |
| Accessories | Standard fittings | Mainframe, back clip, charger, data line, specification, certificate, packing box |
| External camera | Optional button camera and infrared camera (optional) | |
| Interphone | Can be customized according to the interphone model (optional) |
