Automatic Laser Welding Machine for Stainless Steel Processing

Product Description

Product Description
This handheld fiber laser welding machine is one of the most popular welding machines in the current world. It adopts a handheld welding head which is very convenient to operate. It has high welding efficiency and small thermal impact. This machine can weld various metals including thin metal plates.
Features
1. Designed with compact machine body and handheld welding head, this laser welding machine is convenient to use and makes the welding process more flexible. 2. With the function of automatic laser welding, this machine has fast welding speed, about 2-10 times faster than traditional welding machines. 3. Adopting simple control panel, this laser welding machine is easy to learn and simple to operate. No certificate is needed to operate it for beginners. 4. The finished welding seam is smooth and almost doesn't need any further polishing process.
Technical Parameters

Machine power	1000w / 1500w / 2000w / 3000w
laser type	continuous
Laser source	Fiber laser
Cleaning width	10-200mm
Laser wavelength	1080±5nm
Pulse Width	0.05-0.6
Out power Stability	<2%
Weld thickness	2-2.5mm/2-2.5mm/3-4mm/5-6mm
Power Consumption	7KW / 8.2KW / 9.8KW / 13.9KW
Fiber optical length	10m
Model	Regular / mini
Machine size	700*1500*1300mm / 1500*750*850mm
machine weight	240KGS / 160KGS

Detailed Photos






Laser head --
The portable welding joint is light,flexible and easy to operate.
it can be used for continuous welding of various angles and positions.
Control Panel -- The operation is simple and clear,and the system supports
multiple languages.
Laser Source
--
Compared with similar products,the light laser has a higher photoelectric performance conversion ability ,a more stable beam,
and a stronger anti-reflection ability.
Cutting Sample
Certifications

FAQ

1. Do you have the CE document and other documents for customs clearance? A: Yes, we have the Original. At first, we will show you and after shipment, we will give you CE/Packing list/Commercial
Invoice/Sales contract for customs clearance.
2. Payment terms? A: ****** trade assurance/TT/West Union/Paypal/LC/Cash and so on.
3. What's the max. cutting thickness? A: Cutting thickness is related to laser power.Note: only 1KW or above fiber laser could cut Aluminum, Copper, Brass, and other high-reflection sheet metal.
4. Which kind of materials can be processed on this machine?
A: Wood, MDF, stone, acrylic, glass, plastic, foam, aluminum, copper, and almost all kinds of non-steel materials.
5. How long is the delivery time?
A: For standard machines, it will be 7-10 days; For non-standard machines and customized machines according to the client's specific requirements, it will be 15 to 30 days.
