ApplicationHY2110 Geotextile Thickness Tester is used to determine the thickness of geotextile material and related products under different pressure and specified time.StandardISO 9863ASTM D5199GB/T 13761JTG E50 Note: This Geotextile Thickness Tester can conform to but not limit to all the standards above, for more standards conformance, please contact us.Features1. Mechanical structure, simple and easy to operate 2. Digital dial gauge, easy to read, 0~24mm±0.01mm or 0~1±0.001mm optional 3. Main parts are made of stainless steel4. With different press weights, users can select suitable one to testSpecification ModelHY2110Geotextile Thickness TesterPress foot area 25cm2 (diamter: Φ56.42mm )Sample pressure 2±0.01kpa 20±0.1kPa 200±0.1kPaMeasure range0~12±0.001mmDimensions730×320×350mmWeight 40kg
