Sdlg E7150f 15t Wheeled Hydraulic Excavator with Advanced Volvo Technology
| US$76,530.00-89,160.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
shandong lingong
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Size
Large-Scale
Certification
ISO9001: 2000
Condition
New
Overall Operating Weight
13100kg
Max. Digging Radius
7770mm
Max. Digging Depth
4700mm
Max. Digging Height
8395mm
Engine Brand
Deutz
Engine Type
Inter-Cooled, Four-Cylinder, Supercharged
Engine Power
114kw
Emission Standard
Tier III
Min. Fuel-Consume Ratio
196g/Kw.H
Hydraulic Control Type
Pilot Proportional Control Valve
Hydraulic System Type
Twin Pump Constant Power Negative Flow Control
Transport Package
RO-RO, Container
Specification
2490*2496*3543mm
Trademark
SDLG
Origin
Linyi, Shandong, China
Production Capacity
50000unit/Year
Product Description
SDLG E7150F 15t wheeled hydraulic excavator with advanced Volvo technology
E7150F is an energy-saving, reliable and comfortable product that is developed by SDLG's introduction of the advanced
VOLVO technology. It features excellent maneuverability and is equipped with the reinforced working units and optimized
matching hydraulic system for tough conditions.
| Overall dimension | |
| Overall width of upper assembly | 2490mm |
| Overall width | 2496mm |
| Overall height | 3543mm |
| Tail swing radius | 2290mm |
| Ground clearance of counterweight | 1208mm |
| Wheelbase | 2800mm |
| Crawler gauge | 1914mm |
| Min. ground clearance | 350mm |
| Overall length | 7340mm |
| Overall height of boom | 3543mm |
| Overall parameters | |
| Bucket capacity | 0.6m³ |
| Overall operating weight | 13100kg |
| Max. excavation force | 97.7KN |
| Slew speed | 12.2r/min |
| Traveling speed (low/high) | 3.6/37.5km/h |
| Max. digging radius | 7770mm |
| Max. digging depth | 4700mm |
| Max. digging height | 8395mm |
| Max. dumping height | 5943mm |
| Min. front slewing radius | 2613mm |
| Engine | |
| Model | SD60B |
| Type | Four-stroke,inter-cooled, supercharged |
| Rated Power@Revolution Speed | 110kW |
| Displacement | 5700mL |
| Cylinder bore × stroke | 98*126mm |
| Emission standard | GB20891-2014 China Phase III |
| Rated fuel consumption | 214g/kw.h |
| Max. torque | 690N.m |
| Traveling/swing system | |
| Traveling brake type | Wet disc brake |
| Swing mode | Hydraulic drive internal tooth single-row ball-bearing |
| Swing brake type | Wet disc brake |
| Hydraulic system | |
| Hydraulic control type | Pilot proportional control valve |
| Hydraulic system type | Dual pump constant power negative flow control system |
| Max. flow | 160*2+20 |
| Operating pressure | 330kgf/cm2 |
| Fill capacity | |
| Fuel | 260L |
| Engine oil | 25L |
| Hydraulic oil | 265L |
| Antifreeze | 28L |
