50Hz 60Hz C Ummings Engine Silent Natural Gas CHP Cogenerator 100kw 125kVA
| US$32,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SP100N
Output Type
AC Three Phase
Gas Source
Natural Gas
Certification
CE
Power
50-200kW
Standard
Standard
Frequency
50Hz,60Hz Is Available on Request
Voltage
400/230V, Other Voltage Is Available on Request
Fuel
Natural Gas,LPG or Biogas Is Available on Request
Gas Consumption
0.322m3/Kw.H
Rated Power
100kw
Heat Output
168kw
Electrical Efficiency
31.5%
Heat Efficiency
52.9%
Overall Efficiency
84.4%
Gas Pressure
3-5kpa
Certificate
CE
Transport Package
Wrapping
Trademark
WeTeam
Origin
China
HS Code
8502200000
Production Capacity
50pieces/Month
Packaging & Delivery
Package Size
260.00cm * 160.00cm * 170.00cm
Package Gross Weight
2700.000kg
Product Description
50hz 60hz C UMMINGS Engine Silent Natural Gas CHP Cogenerator 100kw 125kvaMultiple units been installed in Europe and have run over than 10,000hours.
GENERAL INTRODUCTION ON SEVENPOWER COGENERATOR SET
-Powered by converted C UMMINGS engine
-Air-cooled type alternator
-Engine heat exchanger
-Exhaust heat exchanger made from full stainless steel,longer service life
-Integrated control cabinet
-Safe gas train
-Gas engine control system
-Auto lambda control,easy start
-All necessary engine protections, oil pressure, coolant temperature, over current, over voltage, overload, engine speed, frequency protection, battery voltage
-Easy control system, all information easily read from the controller screen, power output,voltage,current,power factor, engine speed,oil pressure,coolant temperature,battery voltage,run hours,start numbers,alarms,historical records
Main Specifications
| Model Name | SP100N |
| Frequency (Hz) | 50 |
| Voltage | 400/230 |
| Fuel Type | Natural gas |
| Continuous Power(KWe) | 100kw |
| Thermal Output | 168kw |
| Electrical efficiency | 31.5% |
| Thermal efficiency | 52.9% |
| Overall efficiency | 84.4% |
| Engine | Converted C UMMINGS |
| Alternator | Kwise, other brands is available on request |
| Controller | ComAp |
| Canopy | With or without |
| Genset Gas Inlet Pressure | 3-5kpa |
| Gas consumption@100% load | 0.322m3/kW.h |
For more information about the natural gas cogenerator 100kw, please consult with your sales representative.Thanks.
