Taizhang Factory Pet PP PS PVC Sheet Extrusion Machine
Basic Info.
Model NO.
TANZ-30
Type
Sheet Extruder
Plastic Processed
Pet PP PS etc...
Product Type
Extrusion Molding Machine
Feeding Mode
One Feed
Assembly Structure
Integral Type Extruder
Screw
Single-Screw
Engagement System
Full Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Exhaust
Automation
Automatic
Computerized
Computerized
Conditions of Use
380V/3p/50Hz
Production Raw Materials
Pet Pellets and Regularly Broken Pieces
Sheet Thickness
0.15-2.0mm
Finished Sheet Width
800mm
Extrusion Output
300-350kg/H(Single Screw) ;300-400kg/H(Twin Screw)
Transport Package
Wooden or Standard Package PE
Specification
120/38
Trademark
TANZ
Origin
Dongguan China
HS Code
84772090
Production Capacity
300 Sets of Sheet Line Every Year
Product Description
Product DescriptionAdvanced Pet Sheet Making Machine Discover our cutting-edge Pet Sheet Extrusion Line, meticulously designed for high-quality plastic sheet manufacturing. Rely on Dongguan Taizhang Machinery Co., Ltd. for innovative plastic extrusion equipment. Project Overview:
| 1. Conditions of Use: | 380V/3P/50Hz |
| 2. production material: | PET pellets and regularly broken pieces |
| 3. Sheet material thickness: | Thickness:δ=0.15-1.5mm |
| 4.Finished sheet width: | 800mm |
| 5.Extrusion output: | 300-350Kg/h |
Device Configuration:
| 1 | 120/38 exhaust single screw extruder | 1 set | Include | 120 exhaust extrusion host |
| Two-point automatic suction machine | ||||
| Host quantitative feeder | ||||
| Masterbatch feeding machine | ||||
| Vacuuming system | ||||
| 2 | Hydraulic screen changer | 1set | Include | Double column screen changer |
| Hydraulic system | ||||
| 3 | Melt metering pump | 1 set | Include | Melt pump |
| flow channel | ||||
| Pressure Sensor | ||||
| Cardan shaft | ||||
| Transmission system | ||||
| 4 | Mold | 1 set | ||
| 5 | Three-roller calender | 1 set | Include | Three-roller calender |
| Hydraulic system | ||||
| 6 | Roller temperature control system | 1 set | Three-stage roller temperature control system | |
| 7 | Cooling shaping bracket | 1 set | ||
| 8 | Waste edge trimming device + waste edge winding device (both sides) | 1 set | Include | Waste edge trimming device |
| Waste edge winding device | ||||
| 9 | Silicone oil coating machine + dryer (double-sided) | 1set | Include | Silicone oil coating machine |
| Dryer | ||||
| 10 | Traction device | 1 set | ||
| 11 | Dual station winding machine | 1 set | ||
| 12 | Electrical control system | 1 set |
PET Sheet Extrusion Machine
PET Sheet Extrusion Machine Advantages:
The single screw design maintains original toughness for sheets with good gloss.
Equipped with an exhaust device to remove moisture, saving energy and producing transparent sheets.
Vacuum device ensures clean water extraction for lower defective product rates.
Automatic material suction system reduces manual work and replenishes materials automatically.
Quantitative feeder synchronizes with the main machine to avoid feeding issues.
Cylindrical double-station screen changer minimizes material leakage.
Imported pressure sensor ensures precise synchronization with the metering pump.
Servo motor-driven three-roller calender for precise synchronization.
Servo motor-driven traction device and winding machine with automatic meter counting.
Control system enables fully digital high-precision control.
