| US$1.00-2.00 | 1 Piece (MOQ) |
| PET STYLE SPECIFICATION | UE/300 | |||
| SCREW TYPE | A | B | C | |
| Injection Unit | ||||
| Screw diameter | mm | 55 | 60 | 65 |
| Screw L/D ratio | L/D | 25 | 252 | 25 |
| Shot volume(theoretical) | CM3 | 676 | 805 | 945 |
| Injection weight(PET) | g | 843 | 1004 | 1178 |
| Injection rate | g/s | 307 | 364 | 427 |
| Injection pressure | MPA | 202 | 170 | 145 |
| Screw speed | rpm | 160 | ||
| Clamping Unit | ||||
| Clamping force | KN | 3000 | ||
| Open stroke | mm | 610 | ||
| Space between tie-bars(W*H) | mm | 650*650 | ||
| Max mould height | mm | 630 | ||
| Min mould height | mm | 200 | ||
| Ejector stroke | mm | 170 | ||
| Ejector force | KN | 70 | ||
| Others | ||||
| Max pump pressure | MPA | 16 | ||
| Pump Motor power | KW | 33 | ||
| Heating power | KW | 18.3 | ||
| Numbers of heating area | Segment | 3+1 | ||
| Machine dimension(L*W*H) | M | 6.55*1.72*2.45 | ||
| Oil tank cubage | L | 385 | ||
| Machine weight | TON | 10 | ||
| Name | Brand |
| Computer | KEBA(AUSTRIA) or EST |
| Servo Drive | INOVANCE(CHINA) |
| Servo Pump | SUNNY(USA) / SUMITOMO(JAPAN) |
| Servo Motor | PHASE(ITALY) |
| Electro-hydraulic Proportion valve | HNC (Taiwan) |
| Stroke transducer | NOVO or Miran(GERMANY)/GERFRAN(ITALY) |
| Breaker | Schneider (FRANCEN)/Siemens(GERMANY) |
| Contacts | Schneider (FRANCEN)/Siemens(GERMANY) |
| Switch | Schneider (FRANCEN)/Siemens(GERMANY) |
| Hydraulic Direction Valve | Vickers (USA) or Rexroth (GERMANY) |
| Plasticing Motor | DINAMIC(ITALY) or STF(ENGLAND) |
| Hydraulic Hose | MANULI(ITALY)/CONTINENTAI(GERMANY) |
| Plasticing speed sensor | OMRON |
| Sealing ring | HALITE or TREIIEBORG(UK or GERMANY) |
