Swiss Type CNC Lathe Small Parts High Precision CNC Lathe Machine

Product Description

Product Description
Step into a new era of precision and efficiency with our Compact Swiss Lathe Machine, a true masterpiece of modern engineering. This sophisticated CNC automatic lathe is your gateway to a world of endless possibilities, offering an extensive array of functionalities including tapping, milling, drilling, and turning. Its state-of-the-art design features dual spindles and a revolutionary double Y-axis, enabling simultaneous processing that significantly reduces processing time. This machine is the epitome of innovation, excelling in the batch production of intricate, non-standard components, particularly precision hardware and shafts that require unique and complex shaping solutions.
Product Parameters

Items		SX325
Mechanic	System	FANUC 0i TF-PLUS	SYNTEC 220TB
	Max.RPM	Main8,000min-1/Sub8,000min-1	Main6,000min-1/Sub8,000min-1
	Max.Turning Diameter	φ32mm
	Main Spindle Stroke	280mm
	Rapid traverse speed	32m/min(X1:24m/min)	24m/min
Tools	O.D Tools	6X [16×16]
	I.N Tools	5X [φ20-ER16]
	Cross Driven Tools(integration)	4X [ER16]
	Back end tools(fixed)	4X [ER16]
Motors	Main	5.5/7.5KW	5.9KW
	Sub	1.5/2.2KW	3.9KW
	Cross	0.55/1.1KW	1KW
	Drive	0.75KW	1KW
	Coolant	0.9KW
Others	Coolant tank capacity	200L
	Lubrication tank capacity	1.8L
	Central Height	1,000mm
	Weight	3,800Kg
	The size (L×W×H)	2581×1563×1791mm
NC NC Control	/Controllable Axes	7axis/4axis
	LCD	LCD 10.4"
	System standard parameters	Standard
	Rigid tapping	Standard
	Hand wheel	Standard
	/ Synchronous/hybrid control	Standard
	Helical interpolation	Standard

Items
Standard units	Hand wheel	/C+ Main/Sub axis C + brake
	Floodlight	The product output device
	Transformer	Centralized lubrication system
	Three color light	Synchronus rotary guide bush holder unit
	C:0.001° C axis resolution: 0.001 °	Auxiliary shaft workpiece ejection device
	M Air blow on Sub spindle	Cooling box
0ptionanl units	Bar feeder	Long after loading device
	Chip conveyor	Rectangular power seat
	Oil cooler	Dynamic seat adjustable Angle
	Gun drill	After the end of the quick change perspective
	Oil mist collector	2[ER16]+1 [ER16] 2axis eccentricity tools (rotating)+1axis (fixed)
	High pressure pump	3[ER16] 3axis eccentricity tools (rotating)
	Thread whirling rings	3+[ER16] Back end tools 3axis (rotating)+ 1 axis (fixed)

Detailed Photos
Application
Applications of Swiss Machining
Originating from the renowned Swiss watchmaking industry, Swiss machining technology now caters to a diverse range of applications across various industries. Here are some of the prominent sectors reaping the benefits of this advanced technology:
1) Aerospace
Aerospace is at the forefront of industries leveraging the precision of Swiss machining. The intricate parts, including fans and fasteners, are meticulously crafted using materials such as aluminum alloys and steel. Swiss machines stand out by providing the accuracy and exacting standards demanded by the aerospace sector.
2) Medical devices
The medical industry heavily relies on Swiss-type lathe machines for producing delicate and precise components. With this technology, surgical instruments and implants are crafted to meet the high precision standards required in the medical field, showcasing the significant impact of Swiss machining in healthcare.
3) Electronics
As the complexity and miniaturization of electronic devices continue to grow, conventional methods fall short. Enter CNC Swiss machining- the advanced solution for manufacturing components like connectors and pins. These machines deliver precision and efficiency, perfectly fitting the needs of the dynamic electronics industry.
4) Automotive
In the automotive sector, the intricate and demanding nature of component production finds an ally in Swiss machining solutions. This technology supports the creation of small, complex parts, contributing to the industry's latest mechanical innovations and advancements.
Automotive manufacturers leverage this technology to craft essential parts such as suspension components, carburetor covers, and engine parts. The industry benefits from lower costs, improved manufacturing processes, and enhanced production speeds, securing its competitive edge.
