Used Banbury Gk Hbxm Ge X (S) M-270/250/180/160/110/90/80 X (S) N-110/75/55L/35/20L/15/6/3L Secondhand Kneader Rubber Mixer Internal Mixer Used Kneading Machine

Used Banbury Gk Hbxm Ge X (S) M-270/250/180/160/110/90/80 X (S) N-110/75/55L/35/20L/15/6/3L Secondhand Kneader Rubber Mixer Internal Mixer Used Kneading Machine

US$1.00-100,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
XSM XSN
Certification
CE, ISO, Ghost
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Customized
Status
Used Secondhand
Assembly
Yes
Commissioning
Yes
Shipment
Yes
Transport Package
Wooden Case
Specification
standard container
Trademark
FINEYEAR
Origin
China
HS Code
84778000
Production Capacity
1000 Sets Per Year

Product Description

Parameters\version X(S)N- 110L X(S)N- 35
Working Volume 115 Liter 35
Driving motor power( KW ) 185 KW 55
Tilting motor power ( KW ) 5.5 KW 2.2
Tilting angle 140 ° 140 °
Revolution speed of rotor( front/rear ) 30/24.5 rpm 30/24.5 rpm
Pressure of compressed air 0.6-0.8 MPa 0.5-0.8 MPa
Consumption of compressed air ≥ 1.5 m 3 /min ≥ 0.9 m 3 /min
Pressure of cooling water (rubber mixing ) 0.5-0.6 0.3-0.4
Pressure of heating steam ( plastics mixing ) 0.5-0.8 0.5-0.8
Overall Dimension (mm) 4200x3000x3550 3200x1900x2950
Weight (kg) 14,900 6300

It is mainly used for mixing, plastic refining and final refining of rubber or plastics.
1. According to the user's needs, choose tangent type, joint type, synchronous rotor, etc.
2. The mixing chamber is a drilling structure, with fast heating or cooling speed and good effect. The inner wall is plated with hard chromium or cemented carbide, with a long service life.
3. The upper suppository is driven by air pressure or hydraulic pressure, which can achieve constant pressure control of rubber.
4. The discharge door is driven by a double-rack hydraulic cylinder, and the linear cylinder is locked, with stable work and accurate positioning.
5. The main drive adopts a dual-output shaft hard-toothed gearbox, and adopts a gear coupling or a cross universal coupling. The whole machine has stable transmission, high efficiency, low noise and long service life.
6. The control system adopts PLC, with perfect signal detection, feedback and safety protection, and is easy to operate.

Model GK-45E GK-90E GK-135E GK-160E GK-190E
(L)
Total volume of mixing chamber
45 90 135 160 190
(L)
Working volume of mixing chamber
30 56 90 104 125
(r/min)
Speed of rear rotor
6-60 5-50 6-60 5-50 6-60

Rotor speed ratio
1:1 1:1 1:1 1:1 1:1
(mpa)
Compressed air pressure
0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8
(mpa)
Cooling water pressure
0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4
(kw)
Main motor power
280 450 720 750 1100
(mm)
Overall dimension
(L) 6200 7400 8200 8600 9000
(W) 2500 2880 2950 3000 4000
(H) 3750 4700 5375 6000 6220
(T)
Weight
15 23 29 39 45
Type 16"
Roller Diameter 400mm
Roller Length 1070
Power 37KW
Ratio 1:1.27
Overall Dimension 5000x1800x1600mm
Total weight (kg) 8000
Manufacturer Guangdong, CHINA
Year of Made 2010
