High-Precision Warping Machine for Various Raw Materials and Textiles

High-Precision Warping Machine for Various Raw Materials and Textiles

US$100,000.00-150,000.00 1 Set (MOQ)

Basic Info.

Model NO.
SFZ700
Computerized
Computerized
Precision
High Precision
Certification
ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
After-sales Service
Provide Damaged Parts
PLC
Japan Omron
Screen
Torch Screen
Motor Brand
Siemens/FUJI
Top Speed
700m/Min
Working Width
1800~2800mm
Motor Power
7.5/11/15kw
Creel Style
Fliped/Wheeled
Gifts
Yes
Transport Package
Shipping
Specification
About 7m³
Trademark
Sifang
Origin
China
Production Capacity
30sets/Year

Product Description

Product Description
This exceptional series of machines is expertly designed to accommodate a wide array of raw materials, including chemical fiber filaments, elastic filaments, composite filaments, and more. After multiple creels are harmoniously aligned by the reed, they are meticulously wound into warp shafts. These warp shafts boast uniform and flat density, showcasing the superior benefits of constant tension and impressive high-speed warping. This machine serves as indispensable preparation equipment for both sizing and beaming processes, ensuring excellence in every thread.
Important parts
Creel Part
*Designed with customer needs at the forefront, this component can be customized into fixed, flipped, or wheeled types, offering unparalleled flexibility and convenience.
*Tailored to fit the customer's available site space, this part can be constructed in configurations of two, three, four, six rows, and various threading formats, allowing for seamless integration and operational efficiency.
*Ingeniously fitted with a contact wire breaking stop device, enhancing safety and operational reliability.
*Outfitted with a six-ring tensioner, with alternative tensioner options available, providing optimal tension control and adaptability.
*Equipped with an electrostatic elimination device, ensuring smooth, unhindered operation and superior quality output.
Tension Frame Part
Our innovative clamping tension control method ensures no damage to the thread by eliminating sliding between the thread and rollers during operation. This results in the high-quality production of warp beams for a diverse range of thread types. In the event of a stoppage, the clamping rollers swiftly disengage, thereby preventing any potential damage to the yarn. The advanced positive tension control ensures winding tension remains consistent, thanks to tension feedback from the tension frame, guaranteeing precision and reliability.

Product Parameters
Warping Machine
Top speed 700m/s
The Width of Take-up Working 1800mm 2000mm 2200mm 2400mm 2800mm
The Most Root Number of Warping 2000 2200 2400 2800 3600
Motor drive 7.5kw 11kw 15kw
Tension frame Power 2.2kw 3.7kw 5.5kw
Tension Control Rang -150~+250N
Tension Control Method Clamping Tension Control
Control Scope of Winding Tension 40N~750n

Loading and Unloading System of Warp Shaft Pneumatic device loading and unloading
Diameter of Coiling Plasma Shaft ø800mm~ø1000mm
Display System Touch-operated Displays
Oiling System The Roller-sticker Oiling (Waxing) Method
Auxiliary equipment
prepared by the user
Minimum air pressure 0.65Mpa 0.7Mpa 0.75Mpa
Electrical equipment capacity 15KVA 20KVA 30kva

Creel Part
Style Fliped Type Wheeled Type
Spindle Distance(mm) 270 400 420~470 400 420~470
Max. Bobbin Weight (Max) 6 14 20 14 20
Number of Columns per Frame 5 5 3 4
