China Wholesale Aluminium Alloy Lithium Power Fat Tire 21speed 27.5 Inch Light Weight Mountain Electric Mountain E Bike

China Wholesale Aluminium Alloy Lithium Power Fat Tire 21speed 27.5 Inch Light Weight Mountain Electric Mountain E Bike

US$500.00
10-99 pcs
US$360.00
100-199 pcs
US$200.00
200+ pcs

Basic Info.

Model NO.
EB020
Battery Voltage
48V
Battery Type
Lithium Battery
Wheel Size
26" 27.5" 29"
Motor
Brushless
Frame Material
Aluminum Alloy
Certification
CE
Folded
Unfolded
Max Speed
25km/H
Range per Power
31-60km
Color
Black, Purple, Gray, Blue, Red, or OEM
Brake
Disc Brake
Certificate
CE
MOQ
10 PCS
Frame
Aluminum Alloy
N.W
22 Kg
G.W
26 Kg
Model
Eb020
User
Men/Women
Transport Package
85% SKD Packing, 1PCS/Carton for Electric Bike
Specification
142*25*77CM
Trademark
YIMEI or OEM
Origin
China
HS Code
8711600010
Production Capacity
15000PCS/Month

Packaging & Delivery

Package Size
500.00cm * 105.00cm * 175.00cm
Package Gross Weight
25.000kg

Product Description

China Wholesale Aluminium Alloy Lithium Power Fat Tire 21speed 27.5 inch Light Weight Mountain Electric Mountain E Bike
Frame 27.5 inch frame, aluminum Shift lever Shimano,KSLM610RA DEORE RIGHT 10-SPEED, 2050MM INNER
Fork SF15-XCT-RL-DS 27.5" remote air lockout/ pre-load adjust travel: 100mm 1-1/8" x 225L Rear derailleur Shimano,KRDM610SGSL DEORE SGS 10-SPEED TOP-NORMAL SHADOW DESIGN DIRECT ATTACHMENT Alloy
Head tube assembly Neco,H148M, φ28.6*44*30mm, H: 20mm, conical cover 15mm, W/H2861 aluminum Flywheel Shimano,KCSHG5010136 10-SPEED 11-13-15-17-19-21-24-28-32-36T Steel
Handlebar JB-AL101, 660W*2.4T*6° Knurled part 31.8Φ aluminum Brake lever Shimano,oil disc integrated brake lever
Stem JB-A112-8, Φ28.6*Φ31.8*90EXT*41H*7°, aluminum without LOGO Motor Bafang,M300, 48V, 250W, 3 sensors (torque, crank speed, vehicle speed), CAN-bus controlled
Grip HL-225, 130mm black, with aluminum lock ring and end cap, TPR Display screen Bafang,DPC10, Central bright clear intuitive information screen and easy remote controller
Rim HLQC-29A, 27.5" aluminum rim for double-layer disc brakes, 13G*36H, A/V nozzle. Aluminum Crank Bafang,170mm, flower star center
Tire CST,C-1820, 27.5*2.10 Chainwheel Bafang,11/128"*46T
Inner tube CST, 27.5" X 2.1" L:40mm A/V Battery Li-ion 48V, 10.4Ah 13S4P can bus down tube style with deck and locking system LG 2600 cells
Front hub DH901YF, M9*100*108, 13G*36H, aluminum quick release, effective locking distance 115MM, six-hole aluminum Charger 54.6V2.0A lithium battery charger, DC2.1
Rear hub DH901YR, M10*135*145 13G*36H, 10S card type, locking effective distance 154MM, six-hole aluminum Saddle KS-8016
Disc brake rotor Tektro,TR-180-11 Dia: 180mm with mounting screws Steel Chain KMC,X10 1/2"x11/128" 126L 10S
Disc brake rotor Tektro,TR-160-11 Dia: 160mm with mounting screws Steel Pedal B087DU, all aluminum pedal 9/16 axis, BS reflector aluminum alloy
Product Show
Click here to contact with us
Packaging & Shipping

Other Hot Sale Model
Company Profile Hebei Yimei Bike Co., Ltd is a professional bicycle company, was founded in 2006, located in Fengzhou Industral Park, Pingxiang County, Xingtai City, Hebei Province, China, closed to the largest bicycle parts manufacturing base of China.Our company main products are Mountain bike, Electric bike, Folding bike, City bike, Children bike and so on. We have high quality control system, our products are made of environmentally friendly materials, all the products will be inspected strictly before shipping. And our products have passed CE European certificate and reported, has passed the TUV SGS ROSH and SEDEX inspection.Meanwhile we support OEM service for all customers, have a professional sales team, design team, inspection team, logistics team and after-sales team, to provide customers with the best quality of service and experience.Besides Shanghai international bicycle fair, Guangzhou Canton fair, YIMEI BIKE also attends the MIR DETSTVA Moscow in Russia, in Nuremberg and Cologne Germany, KIDS TIME Kielce in Poland and International famous exhibitions. Now we have build good and long terms business relationship with more than 70 countries, have received good reviews and feedback."Quality first, Reputation above all "is our purpose.Hebei Yimei Bike will be dedicated to the customers to make better and more perfect, more cost-effective and high quality production products and make unremitting efforts.Welcome you to visit our factory! It will be the first step for our strategic cooperation.
FAQ 1.Q: Where is your company located? How can I visit there?
A: Our factory is located in Tian Jin City, China.
2.Q: Can I get sample and how long will it take?
A: Yes. We can supply sample. And you need to pay for the sample and courier. About 10days after receiving the payment, we will send it out.
3. Q: What's the MOQ?
A: Our MOQ is 10 pcs.
4. Q: Can I have my own customized product?
A: Yes. Your customized requirements for color, logo, design, package, carton mark, your language manual etc. We are very welcome
5. Q: Can I mix different models in one container?
A: Yes. Different models can be mixed in one container.
6. Q: What's the delivery time?
A: It will take about 25-35 days to finish an order. But the exact time is according to actual situation.
7. Q: What is the payment terms?
A: T/T, L/C and so on.(Contact with customer our service.)
8. Q: How does your factory carry out quality control?
A: We attach great importance to quality control.Every part of our products has its own QC.
9. How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
