US$23,000.00-45,000.00
|
1 Box
(MOQ)
|
Basic Info.
Type
Multi-Axis Automatic and Semi-Automatic Lathe
Processing Accessory
Centre CNC Lathe
Guide Rail
Vertical Linear Guide
Tool Holder
Single-tool Holder CNC Lathe
Automatic Grade
Automatic
Certification
GS, CE, ISO 9001
Machine Name
Slant Bed CNC Lathe
Machine Type
Slant Bed CNC Turning Center
Machine Model
Ck40p Slant Bed CNC Lathe
Machine Specification
CNC Lathe with Live Tooling
Transport Package
Wooden Case with Iron Foot
Specification
1460x1570x2030mm
Production Capacity
400/Year
Packaging & Delivery
Package Size
1.00cm * 1.00cm * 1.00cm
Package Gross Weight
1.000kg
Product Description
CK40P New Design Slant Bed CNC Turning Lathe Center With Live Tooling
TCK40P Parameter
Model | TCK40P |
Machine structure | 45° |
Guide type | Linear guide |
Guide width | X axis 30 Z axis 30 |
Max swim over bed diameter | 400mm |
Max swim over carriage | 150mm |
Spindle nose to carriage length | 400mm |
X axis travel | 720mm |
Z axis travel | 400mm |
X axis fast move speed | 12000mm/min |
Z axis fast move speed | 12000mm/min |
Spindle type | A2-5 |
Spindle bore | 42mm |
Puller hole diameter | 36mm |
Spindle speed | 4000r/min |
Spindle motor power | 4KW |
Turret type | Gang type tool carrier 5 pieces |
Tool size | 20x20mm |
Tail stock type | Without tail stock |
Machine net weigth | 1.8T |
Machine size | 2100X1600X1800 |
Accuracy |
X axis reposition accuracy | 0.006mm |
Z axis reposition accuracy | 0.006mm |
Diameter uniformity | 0.03/300mm |
Flatness | 0.03/300mm |
roughness | 0.8-1.6 |
Standard Configuration
GSK928 CNC Controller, X Z servo motor and driver
With gang tools post for 4 pieces
Hydraulic collect with hydraulic station and cylinder
Frequency main motor
Auto lubrication system, cooling system, lighting
380v 50hz 3phases
Option:
GSK980, SIEMENS CNC
Hydraulic chuck 6inch
Servo main motor
4 or 8 station electric tool turret
Auto bar feeder oil bath type 3meter,
Chip conveyor
Finished parts collector.
