US$25,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Customized
Non-Customized
Automatic Grade
Automatic
Rotors Type
Roller ,Banbury,Sigma,Delta,Cam
Max.Rotor Speed
250rpm/Min
Transport Package
Plywood
Production Capacity
100/Year
Product Description
The Principle of Mixer
The measuring principle is based on making visible the resistance the sample material opposes to
the rotating rotors. High-speed hot shearing provided by a pair of counter-rotating rotor in the mixer chamber made the material plasticizing from solid to melt.The corresponding torque moves a dynamo-meter out of its zero position .
In compliance with the existing standards and test specifications, a typical ' Rheogram ' (torque and temperature vs. time) is recorded for each sample material. We can analyse the structural changes of the material by the rheogram ,which shows the relationship between torque (viscosity) and temperature / time . The measured data can be displayed and stored numerically as a txt or excel file to further analysis during the measurement .
Technical parameters :
| Mixer-20 | Mixer-60 | Mixer-200 | Mixer-300 |
Chamber volume | 20ml | 60ml | 200ml | 300ml |
Mixer Material | 630 |
Types of rotor | Roller,Banbury,Cam,Delta,Sigma (Roller standard ,others optional ) |
Rotor processing | After high precision polishing, the surface chromium plating |
Speed ratio of rotors | 3:2 |
Temp control system | RKC from Japan |
Temperature sensor | J type thermocouple |
Heating | Electrical Heating/3 zones, PID |
Max. Temperature | 350ºC |
Loading | Manually+ Pneumatic |
Max. rotor speed | 150 or 200 or 240 r/min |
Max. torque | 80Nm | 150Nm | 250 Nm | 250 Nm |
Total power | 1500 W | 1700W | 3600W | 4800W |
Weight | 280 kg |
Dimension(L×W×H) | 650×600×1800 mm |
Types of rotors Rotor is the core component of Mixer System. Different structural type of rotors are suitable for different mixing process and directly affect the products quality ,efficiency and energy consumption. Now, we have developed five kinds of rotors for the plastic and rubber materials ,as illustrated below. The rotors are made of special steel ,counter-rotation towards each other at the speed ratio of 3: 2 provide for excellent compounding and high shear mixing characteristics .
Photo | Name | Function |
| Roller | It is usually used for testing thermoplastic materials and compounding with additives. |
| Banbury | It is usually used for testing natural and synthetic elastomers with regard to flow and cure behavior, compounding with additives . |
| Cam | It is usually used for testing thermo-plastic polymer, ceramic composites, food and other high-torque materials. |
| Delta | It is usually used for testing cross-linking thermo-set polymer . |
| Sigma | It is usually used for testing food, medicine, and plastisol materials, which have low-torque. |
