Crusher for Pet Bottles (SC500/500)

Crusher for Pet Bottles (SC500/500)

Negotiable 1 Set (MOQ)

Basic Info.

Model NO.
(SC500/500)
Type
Plastic Bottle Recycling Crusher
Knife Classification
Rotary and Fixed
Input Capacity
500 Kg/H
Transport Package
Film,Wooded Case,Regular Seaworthy Packing,Ect.
Trademark
BORETECH
Origin
Taiwan
Production Capacity
4 Sets/Quarter

Product Description

Crusher for Pet Bottles (SC500/500)
Water can be added in the grinder with special structural design in the process of crushing to allow the flakes to carry out the first friction cleaning while reducing the temperature in the crushing room and abrasion of the blades; the most important is to reduce the output loss of the powder.
With more than 20 years of experience in the recycling of PET and manufacturing of grinders, we advance in the direction of low failure rate through mechanical structure design, material selection and manufacturing process technology.
-Angle of cutting between rotary blade and fixed blade increases the efficiency of crushing and assure the moving direction of materials in the crushing chamber, reduce the friction and mechanical impact of the materials to the crusher chamber.
- Specially designed machine structure and processing method prevent the material and water leaking from the gap between the screen and chamber in a minimum level.
- The strength of the shaft in the process of material choosing and heat treatment with special designed, so that the shaft will not break.
- Crushing blade, using special processing equipment to weld high wear-resistance steel and carbon steel, extends the service life of blade and decrease production cost while keeping the stability of productive quality.
-The design of blade adjustment frame to make it easier for exchanging blades.
Features:
1. It can smash any plastic material rapidly and can be applied on several usages. It is a smasher with full power.
2. The big plastic materials can be smashed directly without blocking which will result in the stopping of smash. So it can save a lot of time.
3. With water cooling system and the clearance between cutters provide facilities of heat dissipation in order to reduce damage effect between bearings and machine bodies and lessen the depreciation of steel characteristics.
Capacity: 500kgs/hr to 2000kgs/hr with 12mm or 14mm mesh
Specification Output(kg/h) Power(kw) No.of Rotary Blade No.of Fixed Blade Rotor Diameter(mm) Size of Feeding Hopper(mm)
SC500/500 500 45 8 3 500 500*500
SC500/1000 1000 55 16 6 500 500*1000
SC700/1000 1500 75 16 6 700 700*1000
SC800/1200 2000 110 16 6 800 800*1200

*Capacity of above model is based on the minimal size of flakes is 12mm after crushing
1,pre-sale support:
Normally we suggest you paint our standard color , but we can supply customization paint service by paid.
2,after-sale service:
Warranty:1 year for machinery,6 months for electrical.
For mechanical parts, our guarantee duration is 12 months. If the part is broken within this period, we will send the spare parts immediately to the client for repairing.
3,technical support:
Normally, we send our engineer(s) to supervise the installation and commissioning. The buyer need to prepare the operation staff to implement it. BORETECH is able to send mechanical engineer, electrical engineer and operation engineer. The operation engineer is to help the buyer's labors to know how to operate the washing line and get the best efficiency.
Boretech is one of the major supplier of PET bottle recycling system in Asia . We uses the around 30 years of fiber making and bottle recycling experiences to manufacture PET Bottle recycling machine and configure Pelletizing line, Polyester Staple Fiber line, POY line and Bottle to Bottle Line. At present, we have supplied about 170 sets plant for more than 30 countries.Our customers in the US, Japan, EU manufacture food grade rPET resin for such well-known brand owner's such as Coca Cola, Niagara Bottling, Nestle, etc.
Boretech can help our customers to make right configuration of the machinery, and find the right position in the industries. The most important value is that we can help our customers to minimize the learning cost and to avoid making any mistake during investment.
