Jt-1370vs CNC Milling Machine Heavy Duty CNC Verticalmachining Center
| US$34,000.00-45,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Jt-1370VS
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Open-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
Net Weight
10600kg
Standard System
Mitsubishi M80
Tool Libranes
21 Arm Type Tool Libranes
Precision
High Precision
Transport Package
Seaworthy Packing
Specification
4600*2800*3050mm
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500 Sets/Year
Product Description
| ITEM | UNIT | JT-1370VS | |
| Workbench | Workbench size | mm | 1400*700 |
| Worktable load-bearing capacity | kg | 1500 | |
| T-slot width (width x spacing x number of slots) | mm | 18*125*5 | |
| Trip | X-axis travel | mm | 1300 |
| Y-axis travel | mm | 700 | |
| Z-axis travel | mm | 700 | |
| Distance from spindle end face to workbench | mm | 150-850 | |
| Distance from spindle center to Z-axis rail surface | mm | 720 | |
| Principal axis | Speed range | rpm | 6000 |
| Main spindle power (continuous/30 minute rated) | kw | 15/18.5 | |
| Spindle torque(rated for continuous/15minutes) | Nm | 71.6/118 | |
| Slope of spindle inner hole | BT50 | ||
| Transmission mode | Belt-type | ||
| Feed | X-axis rapid displacement | m/min | 20 |
| Y-axis rapid displacement | m/min | 20 | |
| Z-axis rapid displacement | m/min | 20 | |
| Feed rate | mm/min | 15000 | |
| Automatic tool change system | Tool magazine capacity | set | 24 |
| Maximum tool outer diameter (when fully loaded) | mm | 112 | |
| Expanding the diameter of the hollow blade | mm | 200 | |
| Maximum tool length | mm | 350 | |
| Maximum tool weight | kg | 18 | |
| Tool change time (knife to knife) | sec | 5 | |
| Precision VD13441 (JISB6338) | Positioning accuracy | mm | P0.012(±0.005/300) |
| Repetitive accuracy | mm | Ps0.001(±0.003) | |
| Other | Electricity dernad | Kva | 30 |
| Barometric pressure demand (minimum) | kg/cm² | 6 | |
| Cuting fluid capacity | liter | 350 | |
| Machine footprint | mm(approximately) | 4600*2800 | |
| Machine height | mm(approximately) | 2050 | |
| Machine weight | kg(approximately) | 10600 | |
