One Step Vertical LED Diffusor Injection Blow Moulding Machine

One Step Vertical LED Diffusor Injection Blow Moulding Machine

US$10,000.00-75,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
ISB800-3
Making Method of Parison
Injection Blowing
Automation
Automatic
Computerized
Non-Computerized
Certification
CE, ISO9001:2008
Application
Plastic Bottle
After Service
Engineers Available to Service Machinery Oversea
Power
30kw
Warranty
1 Years Warranty
Bottle Material
Pet,PP,PC,PS,PMMA,Tritan
Delivery Time
One Month
Other Service
" Turn-Key "Projects
Transport Package
Wooden Package
Specification
3.8x1.45x3.0m
Trademark
JASU
Origin
China Mainland
HS Code
8477401000
Production Capacity
100PCS/Month

Product Description

JASU Factory One Step INJECTION STRETCH BLOW MOLDING MACHINE ISB800-3
ISB800-3 Main Specification Main Devices Brand
Material PC,PP,PET,TRITAN, PMMA,PS Servo Motor and Oil Pump Phase (Italy) and Eckerle (Germany)
Screw Diameter 40mm Sealing Parts Yuken(Japan), TAIWAN
Screw L/D Ratio 20.5:1 Hydraulic Valve Yuken(Japan), TAIWAN
Screw Speed 0-190 Air Valve AirTAC
Theoretical Injection cavity 238cm3 Air Cylinder AirTAC
Injection Pressure 174Mp Controller (PC) JASU, TAIWAN
Max.hydraulic Pressure 140kg/cm Photosensor Carlo,China
The actual injection quantity 225g(ps),8Oz Safety delay Schneider (ShangHai
Screw Stroke 190mm Servo Motor for Turntable TECO, Taiwan
Blow Clamping Force 80kn Gear Reducer SESAME, Taiwan
Clamp Tonnage 400kn Low-voltage components Joint Venture
Wheel Diameter 800mm Hydraulic hose China
Max.Height Of Bottle 15-150mm F.R.L China
Open Vertical Mode Trip 430mm Hydraulic joint China
Max.Pump Pressure 16Mpa Blowing valve AirTAC(TaiWan)
Servo Motor 22kw Low-pressure cylinder AirTAC(TaiWan)
Electric power 8.9kw low-pressure valve AirTAC(TaiWan)
Tank volume 400L PLC JASU(TaiWan
Dimension of Machine 3.8*1.45*3.0m Air switch Schneider(Shanghai)
Machine Weight 5T Display screen JASU(TaiWan)

JASU injection blow molding machine advantage:
1)Electrical motor and pneumatic drive,avoid hydraulic dirty product.
2) Full automatic control ,easy operation.
3) material barrel and hot runner temperature control accurately.
4) save more cost than traditional machine.
5) compact structure.
6) Injection:
Hot runner and temperature control device and standard configuration only change mold to make a new product.
Blow:
Hydraulic mold clamping,core insert,blow and bottom molding are standard configuration.
Product release :Ejector is a standard device
Jasu injection stretch blowing mould
Gauangzhou Jasu Precision Machinery Co.Ltd is a sabusidiary of JASU International Machinery Group locates in Guangzhou China, which is top 3 supplier of CNC machine tools in South China. JASU owns R&D center and factories in Guangzhou and Suzhou. JASU has been dedicated to manufacturing CNC lathe, machining center, Gantry CNC milling machine and machine tool accessories for 20 years.
Absorbing the design and manufacture of Taiwan and Germany, JASU create a series of highly distinctive, automatic and
cost-effective CNC Machine Tools, machine accessory and one step Injection (Stretch) Blow Molding Machine. JASU has got
high reputation and trust among customers by means of modern management method, perfect quality, novel design and
reasonable price.
Our company faith is "better and faster, it is JASU". We are engaged in providing machines with high quality and best service
to create benefit for enterprise and create value for customer.
JASU group
http://membercenter.made-in-china.com/showroommanage.do?xcase=index
FAQ
Q1: What is the ability of your factory?
A1: About blow molding machine, we could produce 30 sets machine per month.
Q2: Do you have any technical supports about your products?
A2: We have had long term collaboration with German, and we have a lot of cooperation with a lot of advanced manufacture company on the world.
Q3: Do you have any other service about your products?
A3:We have a lot of experience on making complete "Turn-Key" projects and specifications for our clients. Also we have a fixed service system
Q4: All of your products are made by your self or compacted via purchasing the others?
A4: We have independent technical team who focus on making machines; all the products are made by our technical team.
