Mini Diesel Concrete Mixer Tdcm175
| US$1,500.00-2,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
TDCM175-6DB
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
4.5m3/H
Feeding Height
1370mm
Vibrating Amplitude
1.1mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Yellow
Capacity of Discharge
175L
Capacity of Loading
280L
Productivity (M3/H)
4.5
Steel Thickness of Drum
4mm
Mixing Time
40 Sec.
Operation
Hand Feed
Power
5.67kw
Power Source
Diesel Engine
Overall Size
3720*1160*1860mm
Weight
650kg
Transport Package
Nude in Container
Specification
ISO9001
Trademark
kudat
Origin
China
HS Code
8430
Production Capacity
500 Units/Month
Product Description
Easily accessible engine cab and the cove can be removed to get good ventilation for cooling the engine,Four or two towing pneumatic wheel s are optionalSpecifications:
Technical Specification
| Model | TDCM175-6DB |
| Drum total volume (litres) | 580 |
| Unmixed capacity(litres) | 280 |
| Mixing capacity(litres) | 175 |
| Output per hour(m3) | 4.5 |
| Drum rolation(rpm) | 21-25 |
| Engine | Changfa R180BN diesel 5.67KW,Water cooling diesel manual start |
| Steel thickness of drum(mm) | 4 |
| Weight(kg) | 650kg |
| Overall size(mm) | 3720L*1160W*1860H |
| Container loading | 24unit in 40HQ |
Performance:
A rigged with advanced metallurgy and technology. Designed to perform for continuous
mass concreting toughness required at any site Machine
Chassis: Made from rectangular & square tubular sections of high strength
Drum:
Large drum with 20% overload capacity. Fabricated from rolled steel plates. Its bevel
shaped and revolves noiselessly on a single hot blasted ci gear. A quick homogeneous
mix with enhanced daily output is guaranteed
Hopper:
Top Covered ,Centrally Supported Hopper mounted on rectangular tube loaded arm ,
Specifically designed for rapid discharge
Operation Safety :
1 . Light, smooth and positive linkages allows operator fatigue working
2 . Full covered moving parts and dampeners provided in compliance with safety
regulations
3 . Ample space in the engine compartment facilitates air circulation and convenience in
maintenance.
