Condensing Paraffin Wax Granule Forming Machine for Candle Making

Condensing Paraffin Wax Granule Forming Machine for Candle Making

US$50,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
pfm3
Type
Pressing Granulator
Object
Petroleum Resin, Phenolic Resin, Sulfur
Material
Carbon Steel/Stainless Steel
Size
Small
Certification
GS, CE, ISO 9001
Condition
New
Weight
5000kg
Delivery Cycle
5 Weeks
Usage
Candle Molding, Waterproof Building Materials, Che
Heating System
Yes
Cooling System
Yes
Forming System
Yes
Cutting System
Yes
Transport Package
Wooden Package
Specification
10 square meters
Trademark
Support customization
Origin
China Hebei
HS Code
8477800090
Production Capacity
200 Sets Per Month

Product Description

Product Description
Condensing paraffin wax granule forming machine for candle making
A grain wax molding machine is a device specially designed to process grain wax into a specific shape or to further improve the properties of grain wax.
Major component
Feeding system: usually consisting of a hopper and a conveying device. The hopper is used to store the grain wax to be processed, and its capacity depends on the production scale of the machine, the hopper of the small grain wax molding machine may hold dozens of kilograms of grain wax, and the large one can hold several tons.
Forming system: The need for shape regulation may include rolling devices with multiple screens or molds of different apertures and shapes. Can be made into block, plate and other special shape of granular wax products to meet the needs of different industries.
Heating and cooling system: heating methods are generally resistance heating and steam heating. Water cooling is to let the cooling water flow through the cooling pipe or cooling jacket, take away the heat of the wax, cooling speed.
Control system: Modern wax molding machines are equipped with advanced control systems to ensure the stable operation of the equipment and the precise control of the production process.
Product Parameters
specification Minor 1000mm×600mm×1200mm
middle 2000mm×1000mm×1800mm
large 5000mm×2000mm×3000mm
weight Minor 200-500kg
middle 1-3t
large >10t
Dynamic system Motor power 1.5kw-30kw
Rotational speed 1400r/min 2800r/min
Transmission mode Belt/gear/chain drive
Heating system Minor 3-8kw
middle 10-20kw
large 30-60kw
temperature 50 degrees Celsius -150 degrees Celsius
Cooling system Motor power 0.3-3kw
Air cooling system 5-10min
Water cooling system 2-8min
Productive capacity Minor 10-50kg/h
middle 100-500kg/h
large 1000kg/h
Particle size 1-10mm
Company Profile
Dongguang Tiancheng Machinery Factory, located in Chengnan Development Zone, Dongguang County, Cangzhou City, Hebei Province, 50 meters away from National Highway 105, 3 kilometers away from Beijing-Taiwan Highway,
The traffic is very convenient, the factory covers an area of 20 acres, construction area of 5000 square, with perfect cold and hot processing capabilities, the existing various precision processing equipment 30 sets, with a variety of precision machining capabilities, the existing staff of more than 40 people, including 6 engineering and technical personnel, advanced production equipment, perfect testing means, in petrochemical machinery has a good reputation, Well received by users.
The main products of our factory are: a complete set of benzol dewaxing refining equipment and technology, casing crystallizer, plate wax forming machine, particle forming machine, tower granulation, scraper forming machine, rotary condensing granulator and so on. The company has obtained a number of national patents, products sold at home and abroad and a number of large and medium-sized petrochemical enterprises.
Our factory will, as always, adhere to the "customer first, quality first, reputation first, service first" business purpose, strive to pursue excellence, and create brilliant results, welcome new and old customers to visit the company guidance exchange.
