5 Ton Hydraulic Claw Jack Bottle Jack Good Price

5 Ton Hydraulic Claw Jack Bottle Jack Good Price

US$3.90-24.90 100 Pieces (MOQ)

Basic Info.

Model NO.
Hydraulic Bottle Jack
Type
Hydraulic Jack
Structure
Hydraulic Jack
Capacity (Load)
1-10T
Power Source
Hydraulic
Max Height
>400mm
Certification
CE
Condition
New
Product Usage Occasion
Car Repair
Transport Package
Wood Carton
Trademark
AO GE
Origin
Made in China
HS Code
8425190000
Production Capacity
2000 Sets/ Month

Product Description


Capacity Min.H Lifting.H Adjust.H Max.H N.W Package Measurement Qty/Ctn G.W 20' Container
(ton) (mm) (mm) (mm) (mm) (kg) (cm) (pcs) (kg) (pcs)
2 158 90 60 308 2.23 Color Box 52x25.5x19 10 23 7800
3 195 125 60 380 3.2 Color Box 46x26.5x22.5 8 26 5400
4 195 125 60 380 3.2 Color Box 46x26.5x22.5 8 26 5400
5 197 125 60 382 4.1 Color Box 38x27.5x22.5 6 25 4200
6 197 125 60 382 4.1 Color Box 38x27.5x22.5 6 25 4200
8 205 125 60 390 4.9 Color Box 29.5x27.5x22.5 4 20 3340
10 205 125 60 390 5.6 Color Box 30.5x29.5x24 4 23 3000
12 215 125 60 400 6.5 Color Box 30.5x16.5x24 2 13.5 2500
15 225 140 60 425 7.8 Color Box 31.5x17x24.5 2 16 2250
16 225 140 60 425 7.8 Color Box 31.5x17x24.5 2 16 2250
20 244 145 60 449 10.2 Color Box 34.5x19.5x27 2 21 1500
25 244 145 / 389 10.2 Color Box 34.5x19.5x27 2 21 1500
30 285 180 / 465 14 Color Box 37.5x19.5x31 2 28.5 1240
32 285 180 / 465 14 Color Box 37.5x19.5x31 2 28.5 1240
50 300 180 / 480 29.5 Carton 26x24x33 1 30 540

Notes: 1.When the vehicle is jacked up,do not open the engine,because the engine vibrates and the weels of cars turned easy to cause the jack slide down. 2.Before operating the jack, find a fixed position. Operating Instruction 1.Before operating,estimate the weight of the load,Do not overload the jack beyond its rated load. 2.Select point of action according to the gravitational center place the jack on the hard ground if necessary,place a hard plank under the jack so as to avoid tottering or falling during operation. 3.Before operating the jacks,first,insert the notched end of the handle.into the release valve.Turn the operating handle clock wise until release value is closed.Do not over tighten the value. 4.Insert operating handle into the socket and the ram is steadily raised by the up and down movement of the handle and the load is raised.the ram will stop rising when the required height is reached. 5.Lower the ram by turning the release valve.Counterclockwise with the notched end slacken it slowly when a load is applied,or accidents can occur. 6.When more than one jack is used at the same time it is important to operate the different jacks at an equal speed with equal load.Otherwise,there is danger of falling the entire fixture. 7.Violent shocks must be avoided during the operation. 8.User must operate the jack correctly according to operating instruction:If the jacks has some quality problems,it can not be operated.

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
Q1: Are the pallet trucks covered by a warranty?
A: Yes. AII our products carry a full 1-year major parts warranty.
Q2: Can I get discounts?
A: Yes. For big orders, old customers, and frequent customers, we give reasonable discounts.
Q3: Can I place a mixed order? For example, I need 2 pcs electric stacker and 1 pc hand pallet truck, is it ok?
A: Of course. You can mix different models as you wish.
Q4: Can you add our own logo on the products or use our designs?
A: Of course, we provide OEM/ODM service. In addition, we promise your design would protect by law, we won't tell anyone else about this. It's your own copyright.
Q5: Can you send the products to my factory in another city to load the container?
A: Yes, please send us your detailed address, we will arrange to send your factory on time.
