Oscillating Lamp Itl12-1 for Industrial RF Heating Machine

Product Description

Vacuum tube 3CX10000D3/ITL12-1 is a forced air cooled, coaxis structure ceramic-metal, medium-mu power triode containing a thoriated tungsten cathode, with maximum output power up 33kW as continuing operation and up 50kW as pulse operation. The tube is used mianly in industrial radio-frequecy heating service.
GENERAL CHARACTERISTICS
Electrical

Filament	Thoriated Tungsten
Filament Voltage	5.8 V
Filament Current	145 A
Maximum Filament Impact Current	600A
Capacitances:
grid-anode	21 pF
grid-cathode	55 pF
cathode-anode	1 pF
Amplification factor	22
Transconductance (Va: 10 kV, Ia: 4 A)	50 mA/V
Maximum Operation Frequency	120 MHz

Mechanical

Operating position	vertical, anode up or down
Weight	6.5 kg approx.
Diameter	160mm
Height	215.5±5mm

4CX150F 4CX250B/FG 4CX300A 4CX350A/F
4CX1000A 4CX1500A/B 4CX3000A 4CX5000A
4CX10000D 4CX15000A 4CPX150K 6T51 7T62R
E3062 7T69RB 7T84RB 7T85RB 8T25RA 8T85RB
8T87RB 3CX800A7 3CX1500A7 3CX2500A3/F3/H3
3CX3000A1/A7/F1/F7 3CX4500F3(YU-108)
3CX6000A7(YU-148) 3CX10000A3/A7/H3
3CX15000A3/A7/H3 3CX20000H3 3CW30000H3
3CW40000H3 3CW45000H3
6T51 7T62R(E3062C) 8T25RA8T85RB 8T87RB
7T69RB 7T84RB 7T85RB 3CX800A7 3CX1500A7
3CX2500A3/F3/H33CX3000A3/F7/A7 3CX4500/F3
YU-108 3CX6000A7(YU-148) 3CX10000A3/F3/H3
3CX15000A3/F3/H3 3CX20000H3 3CW30000H3
33CW40000H3 3CX45000H3 BW1184J2 BW1185J2
BW1608F RS3060CJ RS3500C TH382 TH347 TH5-6
ITL5-1 TH6-3A
Microwave CW Magnetrons:
2450MHz 850W 950W 1000W 5KW 10KW,
915MHZ 5KW 30Kw,
At the same time, please be kindly to provide us your type needed, and then we can give you our similar products to replace it!
