Akfuluke New Design Hair Color Industrial Cream Vacuum Emulsifyin Mixer Machine

Akfuluke New Design Hair Color Industrial Cream Vacuum Emulsifyin Mixer Machine

US$5,689.00-39,868.00 1 Piece (MOQ)

Basic Info.

Model NO.
FMC-500
Application
Liquid with Suspended Solids, Powder, Viscous Fluid, Liquid, Granules, Cream
Application Area
Metallurgy&Mineral
Certification
CE, ISO, SGS / GMP
Condition
New
Mixing Drum Shape
Disc
Stirring Type
Spiral
Working
High Speed Mixer
Name
Reactor High Pressure Reactor Titanium Reactor Bat
Materials
SUS316L, SUS304
Emulsifying Speed
0-3300rpm
Stirrer Speed
Scraper Mixer : 0-65rpm
Jacked Heating
Steam Heating, Electric Heating
Motor
The Famous Brand of ABB/ Siemens
Control Panel
Can Be Customized Computer PLC or Button Conrtol
Capacity of Reactor
50-5000L ( Designed Your Capacity)
Lift System
Hydraulic Lift
Vacuum Pump
Omron
Mixer Type
Homogenizer
Layout Type
Horizontal
Operating type
Continuous Operating
Warranty
1 Years
Transport Package
Wooden Case
Specification
customized
Trademark
AKFULUKE
Origin
China
HS Code
8479820090
Production Capacity
30set/Month

Product Description


Vacuum homogenizer vacuum mixer homogenizer

Usage and application field
The product is mainly applied in such industries as daily chemical care products, biopharmaceutical industry, food industry, paint and ink, nanometer materials, petrochemical industry, printing and dyeing auxiliaries, pulp&paper, pesticide, fertilizer, plastic&rubber, electric and electronics, fine chemical industry, etc. The emulsifying effect id more prominent for materials of high base viscosity and high solid content.
Definition of vacuum homogenizer emulsifier
It means that when the materials are under the vacuum condition, it makes use of the high shear emulsifier to distribute one or several phases to another continuous phase rapidly and evenly, The materials will be processed in the narrow space between stator and rotor by strong energy of motion produced by the mechanical effect. By the operation of hydraulic shearing, centrifugal extruding. impacting, breaking, and turbulence for over 100 thousand times per minute, the materials will be dispersed and emulsified instantly and evenly . after reciprocation circulation at high frequency, the fine finished products of stable and high quality without bubbles will be achieved.
Performances and features
1. the vacuum emulsifiers produced by our company include many varieties. the homogenizing systems included upper homogenization, lower homogenization, internal and external circulating homogenization. The mixing systems include dingle-way mixing, double-way mixing, and helical ribbon mixing, the lifting systems include single-cylinder lifting and double-cylinder lifting. Various high-quality products can be customized according to customers' requirements.
2. The triple mixing adopts the imported frequency converter for speed adjustment, which can meet different technological demands.
3. The homogenizing structure made through German technology adopts the i, ported double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 4200rpm and the highest shearing fineness can reach 0.2-0.5um.
4. vacuum defoaming can make the materials meet the requirements of being aseptic. Vacuum materials sucking is adopted, and especially for powder materials, vacuum sucking can avoid dust.
5. The emulsifying pot lid can adopt a lifting system, easy to clean and the cleaning effect is more obvious, the emulsifying pot can adopt tilt discharge.
6. The pot body is welded by an imported three-layer stainless steel plat. The tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements.
7. According to technological requirements, the tank body can heat or cool the materials the heating modes mainly included steam heating or electric heating.
8. To ensure the control of the whole machines is more stable, the electric appliances adopt imported configurations, so as to fully meet the international standards.
Main composition :
The vacuum emulsifying mixer is mainly composed of a water pot, oil pot, emulsifying pot, vacuum system,
lifting system (optional), electric control system (PLC is optional ) operation platform, etc.
Main technical
model Effective capacity homogenizer motor
KW
r/min Stir motor
KW
r/min vacuum pump
KW
limit vacuum heating power
steam heating

Electric heating
FMB-10L 10 0.55 0-3600 0.37 0-65 0.37 -0,085 6 2
FMB-50L 50 0.75 0-3600 0.75 0-65 0.75 -0,085 9 3
FMB-100L 100 4 0-3600 1.5 0-65 1.5 -0,085 24 9
FME-200L 200 5.5 0-3300 1.5 0-65 2.2 -0,085 28 10
FME-300L 300 5.5 0-3300 2.2 0-65 2.2 -0,085 32 12
FME-500L 500 7.5 0-3300 4 0-65 4 -0,085 45 16
FMH-800L 800 11 0-3300 5.5 0-65 4 -0,085 54 25
FMH-1000L 1000 11 1400-3000 5.5 0-65 4 -0,085 54 29
FMH-2000L 2000 15 1400-3000 5.5 0-65 5.5 -0,085 63 38

FAQ
1. How will you control the quality and delivery?
All our machines will be tested before packaging. Teaching video and packing pictures will be sent to you for checking, we promise that our wooden packaging is strong enough and safe for long delivery.
2. How to finish installing?
We can guide you through the video or photos first. If the customer needs to install on-site that our engineer can be sent to your country. but customers should pay for the air tickets. besides, customers should arrange accommodation for them during the trip.
3. What do we do if we encounter problems with the machine?
Showing us the picture or video of the problem. If the problem can be solved by your workers, we will send you a solution by video or pictures. If the problem is out of your control, our engineer will be sent to your factory (the customer will pay the fee during the trip).
4. How about a warranty and spare parts?
We provide a 1years warranty for the machine, and most of the parts can be found in the local market or you also can buy the parts from us.
