Durable 22000UF 80V Electrolytic Capacitor for Power Supply
| US$0.001 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
TMCE21
Packaging Type
Screw Terminal
Capacitance
2,2000UF
Structure
Fixed Capacitor
Manufacturing Material
Electrolytic
Electrolyte
Electrolytic
Usage
High Frequency Coupling
Tuning
Electrolytic Capacitor
Filter
Aluminum Electrolytic Capacitor
Rated Voltage Range
10 to 100 and 160 to 450V
Transport Package
Bulk
Specification
CE RoHS Reach Report
Trademark
TOPMAY & ETOPMAY
Origin
China
HS Code
8532229000
Production Capacity
100000PCS/Month
Product Description
TMCE22 Screw Terminal Aluminum Electrolytic Capacitor 105ºC/85ºCProduct Description TMCE22 Screw Terminal Aluminum Electrolytic Capacitor 105ºC /85ºC
TMCE22 Aluminum Electrolytic Capacitor Feature:
1.Capacitor Load life 5000 hours at 105ºC.
2.TMCE22 capacitor long life,higher ripple current than TMCE21 series.
3.Extremely low impedance.
TMCE22 Aluminum Electrolytic Capacitor Screw type 350V 400V 450V 2200UF 2700UF 3300UF 3900UF 4700UF 5600UF 6800UF 10000UF
Aluminum Electrolytic Capacitor Feature:
Compliant to the RoHS directive
Leading product with heat resistance and long life at 85° C to meet the
Requirement for high temperature and long life in the inverter circuit
Details
| SPECIFICATIONS Aluminum Electrolytic Capacitor | |
Item | Specifications |
| Operating Temperature Range | -40°C ~ + 105°C |
| Rated Voltage Range | 350 ~ 450 V.DC |
| Capacitance Tolerance | ±20% (20°C,120Hz) |
| Leakage Current | 0.01 CV (μA) or 5mA, whichever is smaller or less [ C=nominal capacitance (μF), V=rated voltage (v) ] |
| Dissipation Factor | Less than the value specified in the standard prroducts table (20°C, 120Hz) |
| Permissible Ripple Current | As specified in the standard products table (105°C, 120Hz) |
High-Temperature Load | After the rated voltage with specified ripple current is applied at 105°C for 5000 hours: Capacitance tolerance: ±15% or less of the initial value Dissipation factor: 175% or less of the specified initial value Leakage current: Specified intial value or less |
| Other | JIS C 5101-4 |
| RIPPLE CURRENT CORRECTION COEFFICIENT | |||||
| Temperature (°C) | 40 | 60 | 85 | 105 | |
| Coefficient | 2.44 | 2.16 | 2.0 | 1.0 | |
| Frequency (Hz) | 50 / 60 | 120 | 300 | 1K | ≥10K |
| Coefficient | 0.7 | 1.0 | 1.1 | 1.3 | 1.4 |
Photos Show:
