Mu709S-2 HSPA+ Module, MU709S 3G M2M Module

Product Description

Product Description
DescriptionGeneral Features• UMTS/HSPA: 900/2100MHz• GSM/GPRS/EDGE: 850/ 900/ 1800/ 1900 MHz• Output Power UMTS: +24dBm (Power Class 3)GSM850 Class 4 (2 W)GSM900 Class 4 (2 W)GSM1800 Class 1 (1 W)GSM1900 Class 1 (1 W)• Sensitivity GSM 850/900 MHz: -110 dBmGSM 1800/1900 MHz: -109 dBmWCDMA 900 MHz: -112 dBmWCDMA 2100 MHz: -111 dBm• AT commands 3GPP TS 27.007 and 27.005extended AT command• Power supply: 3.0 V to 3.6V (typical: 3.3V)• Temperature range: -40° C to 70° C• Humidity: 5% - 95%• Dimensions: 30.4 mm x 51 mm x 3.4mm• Weight: approx. 12g• USB driver for Linux/Android Voice• DTMF support*• PCM voice support• Voice codec: AMR (all rates)Data• HSPA: UL 5.76 (Mbps)/ DL (21.6 Mbps)• WCDMA PS: UL (384 kbps)/ DL (384 kbps)• EDGE: UL (236.8 kbps)/ DL (236.8 kbps)• GPRS: UL (85.6 kbps)/ DL (85.6 kbps)SMS• MO / MT• Text / PDU modeAdditional Features• FOTA•STK (SIM Took Kit)• Firmware udate via USB• Embedded TCP/IP stackSupplementary Service• Call forwarding / hold / waiting• USSDInterfaces• 3 Antenna connectors• PCIE interfaces• USB 2.0 High speed• PCM Voice• SIM Interface (1.8V / 3.0V)• Power supply• ResetApprovals & Certifications• CCC• CE•GCF *) features will be ready in future version, test sample would not be available for this features. Note:Please refer to the latest version of Hardware Guide about the specifications. reserves the right to make changes or improvements to any to the products without prior notice. Why Choose UsFAQQ1. What is the minimum order quantity for your products?A1. Minimum order quantity starts from ONE piece.Q2. What's the quality of your products?A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products.Q3. Is this product free of shipping or free samples?A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.All Categories4G 5G ModuleGPS ReceiverGPS AntennaGSM/LTE/WiFi AntennaGSM/LTE+GPS AntennaGNSS/GPS Module2G/3G/4G ModemGPS TrackerRF Coaxial / ConnectorSIMCard HolderSensorIC
