US$25,000.00-26,000.00
|
1 Set
(MOQ)
|
Basic Info.
Required Paper
Both Single and Double PE Coated Paper
Logo Printing
Without Logo Printing
Voltage Supply
220V50Hz/380V50Hz or Customized
Usage
Packing Paper Machine, Office Paper Machine
Paper Request
150-350G/M2
Transport Package
Woodencase
Trademark
Lifeng machinery
Production Capacity
60set/Month
Product Description
Machine Description
LF-110 Middle-speed paper cup forming machine is a machine that have double turntable, dual-segment high-performance with functions of automatic paper fan feeding, hot air heater side seal, cup top lubrication, automatic bottom paper feeding, curling artwork, automatic cup collect and stock. Can make cups both single PE and double PE, for cold drinks and hot drinks. This machine speed can reach100-120pcs/min.
Advantages:
1)The core components adopt open cam design, with gear motor.
2)Machine has full automatic lubrication by oil pump and filtration, more convenient for maintenance.
3)The hot air heating system make the bottom sealed in a short time and high sealing quality.
4)Control panel use touch screen, a clearer vision, the whole electrical appliances adopt imported configuration, have high generality and good performance, and facilitate equipment maintenance.
5)The machine is controlled by PLC, and has a encoder to control the working of ultrasonic, sensors, solenoid valve and so on, to make the running of each process more accurately.
6)Use new rotary type paper fan feeding system, instead of traditional linear bearing, to ensure machine performance more stable and faster machine speed.
Mail technical parameters
GENERAL POWER | 16kw |
PAPER REQUEST | 150-350g/ M^2 (BOTH SINGLE PE & DOUBLE PE COATED PAPER) |
POWER SUPPLY | 220V50Hz/ 380V50Hz OR CUSTOMIZED |
CUP SIZE | 4-16OZ |
SPEED | 100-120PCS/MIN |
WEIGHT | 2500kgs |
DIMENSION | 2600*1400*1900mm |
| |
MAIN PART LIST:
Motor | Main motor | China ZHIBAO |
Knurling/ curling motor | China ZHIBAO |
Configuration | guide rail | Taiwan HIWIN |
Straight line bearing | JAPAN NSK |
, cutting mold and knurling | Cr12MoV Quenching |
open cam | 20CrMoTi Carburizing and quenching |
gear | 20CrMoTi Carburizing and quenching |
bearing | JAPAN NSK |
Turnplate | Aluminium alloy 5A02 |
Electric elements | TOUCH SCREEN | DELTA |
PLC | DELTA |
ULTRASONIC | EVERGREEN Ultrasonic |
Hot air heater | Switzerland |
encoder | OMRON |
Frequency converter | DELTA |
Contactor (switch ) | SCH NEIDER |
Sensor | PANASONIC(JAPAN) |
AFTER SERVICE
1. Warranty: 1 year
2. The guide booklet will be sent with machine to guide the installation process works, adjust the whole machine, production, avoide or solve the
Problem which the buyer will face.
3. We will adjust the machine well for one week before the delivery, ensure the machine has the perfect performance.
4. We can dispatch technologists to buyer's factory, guiding installation, adjustment for a period, the buyer incharge of the salary, traffic fee, boarding and lodging, communication and each day 100USD living allowances.
5. We supply the free training of buyer, the training won't stop until the buyer control the whole leson! The cost of air ticket, boarding and lodging should provided by buyer.
6. We supply the consumable spare parts for free for one year use.
